English 11
3 Turn the shaping disc holder counterclockwise to
remove it from the mixing chamber outlet.
4 Put your nger in the mixing chamber and push the squeezing tube outwards to
slide it out of the mixing chamber outlet. Detach the shaping disc, and then pull
the squeezing bar out of the squeezing tube.
5 Take the mixing paddle out of the mixing chamber.
6 Clean all detachable parts and accessories, and then
wipe them dry.
1
2
3
