Page #9 background imageLoading...
Page #9 background image
7EN
h HDMI OUT (ARC)
Connect to the HDMI input on the TV.
i AUDIO IN-AUX
Connect to an analog audio output on the
TV or an analog device.
3 Connect and set
up
This section helps you connect your home
theater to a TV and other devices, and then set
it up.
For information about the basic connections
of your home theater and accessories, see the
quick start guide.
Note
For identication and supply ratings, see the type plate
at the back or bottom of the product.
Before you make or change any connections, make sure
that all devices are disconnected from the power outlet.
Connect speakers
The speaker cables are color-coded for easy
connection. To connect a speaker to your home
theater, match the color on the speaker cable to
the color on the connector.
Speaker position plays a critical role in setting
up a surround sound effect. For best effect,
position all the speakers towards the seating
position and place them close to your ear level
(seated).

Other manuals for Philips HTB3520

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Philips HTB3520 and is the answer not in the manual?

Philips HTB3520 Specifications

Sound Specifications IconSound Specifications
total power RMS1000 W
center speaker output power166 W
satellite speaker output power4 x 166 W
subwoofer output power166 W
Loudspeakers IconLoudspeakers
center speaker frequency range150 - 20k Hz
center speaker impedance3 ohm
satellite speaker frequency range150 - 20k Hz
satellite speaker impedance3 ohm
subwoofer frequency range20 - 150 Hz
subwoofer impedance3 ohm
Power IconPower
power consumption160 W
power supply110 - 127 V / 220 - 240 V, 50/60 Hz
standby power consumption< 0.5 W
Packaging Dimensions IconPackaging Dimensions
packaging dimensions (W x H x D)53.8 x 49.3 x 37.6 cm
gross weight11.88 kg
nett weight10.56 kg
tare weight1.32 kg
Product Dimensions IconProduct Dimensions
product dimensions (W x H x D)43.5 x 5.8 x 28 cm
weight2.64 kg
Dimensions IconDimensions
center speaker dimensions (W x H x D)314 x 110 x 83 mm
main unit dimensions (W x H x D)435 x 58 x 280 mm
rear speaker dimensions (W x H x D)100 x 192 x 125 mm
subwoofer dimensions (W x H x D)230 x 370 x 310 mm
front speaker dimensions (W x H x D)100 x 192 x 125 mm
