LOCATION OF PCB BOARDS
CONTROL PCB
STANDBY PCB
MP3 PCB
MAIN PCB
IPOD PCB
POWER PCB
USB PCB
VERSION VARIATION:
Type/Versions
Features & Board in used
HTS3544
/37
Main (Output Power-1000W)
Composite Video Out
Power Voltage (120V)
AC Cord (Fix)
