10 EN
Main unit
a 2
Turn on this unit or turn off to standby
mode.
b Disc compartment
c ç (Open/Close)
Open or close the disc compartment.
d Display panel
e VOLUME
Adjust the volume level.
f u (Play/Pause)
Start or pause disc play.
RADIO: start auto radio installation
(only available for fi rst time setup).
x (Stop)
Stop disc play.
RADIO: erase the current preset radio
station.
. / >
Skip to the previous or next title/
chapter/track.
Press and hold for fast backward or
forward search.
RADIO: select a preset radio station.
•
•
•
•
•
•
•
•
•
•
g SOURCE
Select a play media: DISC, FM, AUX1,
AUX2, DI (DIGITAL IN) or MP3 LINK.
Note
The following sockets are under the fl ap at the right
corner of the main unit (OPEN B).
•
h MIC socket
To connect microphone.
i MP3 LINK socket
To connect portable audio player.
j MIC LEVEL
Switch to microphone mode. Then
adjust the volume control to set the
microphone volume level.
k USB socket
To connect USB fl ash drive, USB
memory reader or digital camera.
•
•
•
•
•
1
2
3 4
5 6
8
7
9
10 11
