Installation Instructions 5 Installing E12
15
2
Pull off the front housing. Do not pull the display off completely, only tilt it to the front, because
otherwise the flex panel adapter could be damaged.
Reassembly Note: Make sure the metal sheet on the back of the display is inserted into the noses of the
monitor rear housing when reassembling the two halves.
NOTE The pictures in some of the following steps already contain an inserted internal module slot rack.
