1Introduction
This document contains or refers to proprietary information which is protected by copyright. All rights
are reserved. Copying or other reproduction of this document is prohibited without the prior written
permission of Philips Medical Systems.
WARNING The electrical characteristics of anti-static mats should be checked before use, as described in the
manufactuerer’s instructions for continued protection to both you and the equipment.
CAUTION A recommended anti-static table mat is the Minnesota Mining and Manufacturing Company (3M)
Part Number 8210. In addition to the table mat the person disassembling the monitor should either:
1 Wear a conductive wrist strap (#M Part No. 2046) attached to the mat by the 1.2 m (4”) wire
included with it, or
2 Stand on a floor mat with leather-soled shoes.
Before handling any circuit boards, firmly touch the exposed metal on the case to equalize the ground
potentials. This will prevent static discharge and protect the logic components of the monitor.
Handle circuit boards on the edges only; avoid touching board surfaces unless performing circuit board
repair. Contaminants like skin oil will attract dust to accumulate which could retain moisture and
affect the circuit performance.
