Mounting Luminaire 9
SL STRIP 400 TW LED Luminaires
Installation & User’s Manual
Sh wline
4. Mounting Luminaire
The SL STRIP 400 TW LED Luminaire is provided with two mounts and a safety cable anchor point (as described in
"Major Luminaire Components" on page 4).
The two mounts are easily removed and reversed as required (as illustrated in Figure 6). These mounts are designed
to accept a variety of mounting hooks, clamps, etc. for hanging applications or can be set on the mounts for floor
applications. Refer to Figure 7 for additional information.
Figure 6: Mount Removal and Installation
OR
OR
Mount Screws (x2)
Mount
Mount
Mount Screws (x2)
Luminaire
