Philips LC4.1E User Manual

Spare Parts List
EN 61LC4.1E AB 10.
10. Spare Parts List
Set Level
Various
0032 3341 101 20021 Power Supply Unit
(15 inch)
0032 3122 137 23041 Power Supply Unit
(17 inch)
0032 3122 137 23101 Power Supply Unit
(20 inch)
0032 3122 137 23071 Power Supply Unit
(23 inch)
0041 3139 124 62171 PC LENS
8105 3139 131 04951 Cable 04p/220
b
5213 2422 264 00541 Loudspeaker 5W
fullrange
Small Signal Board [B]
e Software (see Philips Service Website)
0606 Hercules SW
0611
Scaler SW
Various
1001 2422 543 01414 Xtal 24.576MHz
1007 2422 025 08149 Connector 6p m
1008 2422 025 09405 Connector 2p m
1010 2422 025 18734 Connector 11p m
1101 4822 265 10703 Socket scart 21p
1302 3139 147 19801 Tuner UV1318S/A IH -3
1302 3139 147 23021 T
uner UR1316S/A I H-3
1328 2422 549 44372 SAW 38.9MHz K3953L
1330 2422 549 44369 SAW 38.9MHz K9656L
1331 4822 267 10459 Connector 3p
1401 2422 025 09406 Connector 4p m
1402 2422 025 18024 Connector 40p m
1403 2422 543 01374 Xtal 14.318 Mhz
1404 2422 025 18314 Connector 20p m v 1.25
1485 2422 033 00484 Socket DVI 24p f
1485 2422 033 00515 Socket DVI-I 29p f
1684 2422 025 10768 Connector 3p m
1701 2422 025 10768 Connector 3p m
1751 2422 025 18739 Connector 5p m
1910 2422 025 18746 Connector 12p m
1951 2422 025 18752 Connector 5p m
8010 3104 311 10781 Cable 10p/140/10p
8401 3139 110 27731 Cable 04p/080/04p
8401 3139 131 06171 Cable 04p/220/04p
8701 3103 308 90612 CWAS 03PH/03PH 220
BK AWG26
8751 3139 131 06261 Cable 05p/300/05p
8910 3139 110 28271 Cable 12P
8910 3139 131 04311 Cable 12p 180
8951 3104 157 02361 Cable 5p 280
g
2001 2238 586 59812 100nF 20% 50V 0603
2004 3198 017 42240 220nF 16V Y5V 0603
2008 3198 017 44740 470nF 10V 0603
2009 3198 017 41050 1µF 10V 0603
2010 5322 126 11582 6.8nF 10% 63V
2011 3198 017 42240 220nF 16V Y5V 0603
2012 4822 124 23002 10µF 16V
2013 2238 586 59812 100nF 20% 50V 0603
2016 2238 586 59812 100nF 20% 50V 0603
2017 2238 586 59812 100nF 20% 50V 0603
2018 5322 126 11583 10nF 10% 50V 0603
2023 3198 017 42240 220nF 16V Y5V 0603
2024 4822 124 12084 1µF 20% 50V
2027 2238 586 59812 100nF 20% 50V 0603
2030 2238 586 59812 100nF 20% 50V 0603
2031 2238 586 59812 100nF 20% 50V 0603
2032 2238 586 59812 100nF 20% 50V 0603
2033 3198 017 42240 220nF 16V Y5V 0603
2035 2020 021 91729 4.7µF 20% 35V
2036 4822 126 11785 47pF 5% 50V 0603
2037 4822 126 11785 47pF 5% 50V 0603
2043 2238 586 59812 100nF 20% 50V 0603
2044 3198 017 42240 220nF 16V Y5V 0603
2049 4822 124 23002 10µF 16V
2051 4822 124 23002 10µF 16V
2052 3198 016 31020 1nF 25V 0603
2053 2238 586 59812 100nF 20% 50V 0603
2054 2238 586 59812 100nF 20% 50V 0603
2055 2238 586 59812 100nF 20% 50V 0603
2056 2238 586 59812 100nF 20% 50V 0603
2057 2238 586 59812 100nF 20% 50V 0603
2058 3198 016 31020 1nF 25V 0603
2060 2238 586 59812 100nF 20% 50V 0603
2061 4822 124 23002 10µF 16V
2063 3198 017 31540 150nF 10V 0603
2067 3198 016 31020 1nF 25V 0603
2068 3198 017 42240 220nF 16V Y5V 0603
2072 3198 017 42240 220nF 16V Y5V 0603
2073 5322 126 11583 10nF 10% 50V 0603
2074 3198 017 42240 220nF 16V Y5V 0603
2076 3198 017 42240 220nF 16V Y5V 0603
2078 2020 552 94427 100pF 5% 50V
2082 2238 586 59812 100nF 20% 50V 0603
2083 2020 552 96637 10µF 10% 6.3V 0805
2099 3198 016 31020 1nF 25V 0603
2101 4822 126 14241 330pF 0603 50V
2102 4822 124 23002 10µF 16V
2103 4822 126 14241 330pF 0603 50V
2104 4822 126 14491 2.2µF 10V 0805
2105 4822 126 14241 330pF 0603 50V
2106 4822 124 23002 10µF 16V
2107 4822 126 14241 330pF 0603 50V
2108 4822 126 14491 2.2µF 10V 0805
2307 3198 017 34730 47nF 16V 0603
2309 2020 012 00029 330µF 6.3V
2311 4822 124 23237 22µF 6.3V
2313 5322 126 11578 1nF 10% 50V 0603
2314 2238 586 59812 100nF 20% 50V 0603
2317 5322 126 11578 1nF 10% 50V 0603
2318 5322 126 11578 1nF 10% 50V 0603
2321 5322 126 11583 10nF 10% 50V 0603
2324 5322 126 11583 10nF 10% 50V 0603
2357 2238 586 59812 100nF 20% 50V 0603
2359 5322 126 11583 10nF 10% 50V 0603
2372 2238 586 59812 100nF 20% 50V 0603
2374 2238 586 59812 100nF 20% 50V 0603
2375 4822 124 23002 10µF 16V
2376 2238 586 59812 100nF 20% 50V 0603
2377 2238 586 59812 100nF 20% 50V 0603
2378 3198 017 42240 220nF 16V Y5V 0603
2379 3198 017 42240 220nF 16V Y5V 0603
2380 4822 124 12095 100µF 20% 16V
2381 2238 586 59812 100nF 20% 50V 0603
2382 2020 552 00035 2.2µF 6.3V 10% 0603
2383 2020 552 00035 2.2µF 6.3V 10% 0603
2384 2020 552 00035 2.2µF 6.3V 10% 0603
2385 2020 552 00035 2.2µF 6.3V 10% 0603
2386 3198 017 42240 220nF 16V Y5V 0603
2387 2020 012 00029 330µF 6.3V
2388 2020 012 00028 470µF 20% 16V
2389 4822 126 11785 47pF 5% 50V 0603
2390 4822 126 11785 47pF 5% 50V 0603
2394 2238 586 59812 100nF 20% 50V 0603
2395 2238 586 59812 100nF 20% 50V 0603
2401 4822 124 11131 47µF 6.3V
2402 2238 586 59812 100nF 20% 50V 0603
2403 2238 586 59812 100nF 20% 50V 0603
2404 2238 586 59812 100nF 20% 50V 0603
2405 2238 586 59812 100nF 20% 50V 0603
2406 2238 586 59812 100nF 20% 50V 0603
2407 2238 586 59812 100nF 20% 50V 0603
2408 2238 586 59812 100nF 20% 50V 0603
2409 2238 586 59812 100nF 20% 50V 0603
2410 2238 586 59812 100nF 20% 50V 0603
2411 2238 586 59812 100nF 20% 50V 0603
2412 2238 586 59812 100nF 20% 50V 0603
2413 2238 586 59812 100nF 20% 50V 0603
2414 2238 586 59812 100nF 20% 50V 0603
2415 2238 586 59812 100nF 20% 50V 0603
2416 2238 586 59812 100nF 20% 50V 0603
2417 2238 586 59812 100nF 20% 50V 0603
2418 4822 126 13883 220pF 5% 50V
2419 4822 126 13883 220pF 5% 50V
2420 4822 124 11131 47µF 6.3V
2421 2238 586 59812 100nF 20% 50V 0603
2422 2238 586 59812 100nF 20% 50V 0603
2423 2238 586 59812 100nF 20% 50V 0603
2424 2238 586 59812 100nF 20% 50V 0603
2425 2238 586 59812 100nF 20% 50V 0603
2426 4822 126 13883 220pF 5% 50V
2427 4822 126 13883 220pF 5% 50V
2429 2238 586 59812 100nF 20% 50V 0603
2430 2238 586 59812 100nF 20% 50V 0603
2431 2238 586 59812 100nF 20% 50V 0603
2432 2238 586 59812 100nF 20% 50V 0603
2433 2238 586 59812 100nF 20% 50V 0603
2434 2238 586 59812 100nF 20% 50V 0603
2435 4822 126 13883 220pF 5% 50V
2436 4822 126 13883 220pF 5% 50V
2438 2238 586 59812 100nF 20% 50V 0603
2439 2238 586 59812 100nF 20% 50V 0603
2440 2238 586 59812 100nF 20% 50V 0603
2441 2238 586 59812 100nF 20% 50V 0603
2442 2238 586 59812 100nF 20% 50V 0603
2443 3198 016 35680 5.6pF 0.5pF 50V 0603
2444 3198 016 35680 5.6pF 0.5pF 50V 0603
2445 2238 586 59812 100nF 20% 50V 0603
2448 2238 586 59812 100nF 20% 50V 0603
2450 4822 126 13883 220pF 5% 50V
2451 4822 126 13883 220pF 5% 50V
2452 5322 126 11583 10nF 10% 50V 0603
2463 2238 586 59812 100nF 20% 50V 0603
2471 4822 124 11131 47µF 6.3V
2472 2238 586 59812 100nF 20% 50V 0603
2473 2238 586 59812 100nF 20% 50V 0603
2474 2238 586 59812 100nF 20% 50V 0603
2475 2238 586 59812 100nF 20% 50V 0603
2476 2222 867 15339 33pF 5% 50V 0603
2477 3198 017 41050 1µF 10V 0603
2478 3198 017 41050 1µF 10V 0603
2479 3198 017 41050 1µF 10V 0603
2483 2238 586 59812 100nF 20% 50V 0603
2485 3198 017 41050 1µF 10V 0603
2486 3198 017 41050 1µF 10V 0603
2487 3198 017 41050 1µF 10V 0603
2488 4822 122 33761 22pF 5% 50V
2489 4822 122 33761 22pF 5% 50V
2490 2238 586 59812 100nF 20% 50V 0603
2510 2238 586 59812 100nF 20% 50V 0603
2513 4822 124 23002 10µF 16V
2514 3198 016 31590 15pF 10% 50V 0603
2515 5322 126 11583 10nF 10% 50V 0603
2516 3198 016 36810 680pF 25V 0603
2517 5322 126 11583 10nF 10% 50V 0603
2518 5322 126 11583 10nF 10% 50V 0603
2519 3198 016 31020 1nF 25V 0603
2520 2238 586 59812 100nF 20% 50V 0603
2521 5322 126 11583 10nF 10% 50V 0603
2522 5322 126 11583 10nF 10% 50V 0603
2523 5322 126 11583 10nF 10% 50V 0603
2524 5322 126 11583 10nF 10% 50V 0603
2525 5322 126 11583 10nF 10% 50V 0603
2526 5322 126 11583 10nF 10% 50V 0603
2527 5322 126 11583 10nF 10% 50V 0603
2703 4822 124 23002 10µF 16V
2712 3198 017 41050 1µF 10V 0603
2714 2020 012 00028 470µF 20% 16V
2718 3198 017 41050 1µF 10V 0603
2719 2238 586 59812 100nF 20% 50V 0603
2724 4822 124 41584 100µF 20% 10V
2736 4822 124 80791 470µF 20% 16V
2737 4822 124 80791 470µF 20% 16V
2738 3198 016 31020 1nF 25V 0603
2739 3198 016 31020 1nF 25V 0603
2741 4822 126 13881 470pF 5% 50V
2742 4822 126 13881 470pF 5% 50V
2910 4822 126 13881 470pF 5% 50V
2911 2022 031 00308 22µF 20% 35V
2920 4822 124 80151 47µF 16V
2921 4822 124 80151 47µF 16V
2930 4822 124 80791 470µF 20% 16V
2931 4822 126 13881 470pF 5% 50V
2933 4822 124 80791 470µF 20% 16V
2934 4822 126 13193 4.7nF 10% 63V
2936 5322 126 11578 1nF 10% 50V 0603
2937 5322 126 11578 1nF 10% 50V 0603
2938 5322 126 11578 1nF 10% 50V 0603
2939 5322 126 11578 1nF 10% 50V 0603
2940 5322 126 11578 1nF 10% 50V 0603
2941 5322 126 11578 1nF 10% 50V 0603
2942 5322 126 11578 1nF 10% 50V 0603
2943 4822 124 80195 470µF 20% 10V
2959 2238 586 59812 100nF 20% 50V 0603
2960 4822 124 80151 47µF 16V
2961 5322 126 11583 10nF 10% 50V 0603
2962 2238 586 59812 100nF 20% 50V 0603
2963 2238 586 59812 100nF 20% 50V 0603
2994 4822 124 11131 47µF 6.3V
2995 2238 586 59812 100nF 20% 50V 0603
2996 2238 586 59812 100nF 20% 50V 0603
2997 4822 124 11131 47µF 6.3V
