44LC4.41E AA 7.

Circuit Diagrams and PWB Layouts

SSB: Diversity Tables B1-B6

Item nr.

EU non DVB

EU DVB

Description

1152 TUN V+U PLL IEC BGHIL B

TUNER UV1318SD/A CP H N-4

3163 RST SM 0603 100R PM5 COL

3164 RST SM 0603 100R PM5 COL

5152 FXDIND SM 1008 1U PM5 COL R

FXDIND SM 1008 6U8 PM5 COL R

5157 FXDIND 0603 100MHZ 600R COL R

5158 FXDIND 0603 100MHZ 600R COL R

B01

B02

B03

B05 B06

Item Nr.

/93 China

AP 10pg TXT

EU 10pg TXT

EU 10pg TXT DVB

EU 1000pg TXT

EU 1000pg TXT DV

Description

2203 319803041090 ELCAP SM 16V 10U PM20 COL R

2244 319803571040 CER2 0402 Y5V 16V 100N COL

2245 319803571040 CER2 0402 Y5V 16V 100N COL

2246 319803571040 CER2 0402 Y5V 16V 100N COL

2280 202055200005 CER2 0603 X5R 6V3 4U7 PM10 R

2281 202055200005 CER2 0603 X5R 6V3 4U7 PM10 R

2289 319802131510 RST SM 0603 150R PM5 COL

2290 222224059872 CER2 0805 Y5V 10V 4U7 P8020 R

2291 319803571040 CER2 0402 Y5V 16V 100N COL

3250 319803101010 RST SM 0402 100R PM5 COL

3251 319803101010 RST SM 0402 100R PM5 COL

3252 319803101010 RST SM 0402 100R PM5 COL

3253 319803101010 RST SM 0402 100R PM5 COL

3255 319803190010 RST SM 0402 JUMP. 0R05 COL

3256 319803190010 RST SM 0402 JUMP. 0R05 COL

3257 319803190010 RST SM 0402 JUMP. 0R05 COL

3258 319803101020 RST SM 0402 1K PM5 COL

3259 319803101020 RST SM 0402 1K PM5 COL

3260 319803101020 RST SM 0402 1K PM5 COL

3282 319802131510 RST SM 0603 150R PM5 COL

3294 319803104730 RST SM 0402 47K PM5 COL

3296 319803101010 RST SM 0402 100R PM5 COL

4206 319802190020 RST SM 0805 JUMP. 0R05 COL R

4218 319803190010 RST SM 0402 JUMP. 0R05 COL

4219 319803190010 RST SM 0402 JUMP. 0R05 COL

5218 242254945333 IND FXD 1206 EMI 100MHZ 120R R

6206 319801010660 DIO SIG SM BAT54 SOD323 COL R

7208 319801042310 TRA SIG SM BC847BW (COL) R

7209 319801042310 TRA SIG SM BC847BW (COL) R

7210 319801042310 TRA SIG SM BC847BW (COL) R

7217 935280215557 IC SM TDA15031H/N1C91 (PHSE)Y

935280366557 IC SM TDA15021H/N1C91 (PHSE) Y

935280367557 IC SM TDA15011H/N1CD0 (PHSE) Y

7219 319801071090 IC SM 74HC4053D (COL) R

Item Nr.

10pg TXT (w/o OTC)

1000pg TXT (with OTC)

DVB 10pg TXT (w/o OTC)

DVB 1000pg TXT (with OT

Description

1442 242202519085 CON V 14P M 1.00 SM SR R

3432 319803102720 RST SM 0402 2K7 PM5 COL

6430 934054842115 DIO REG SM PDZ2.4B (PHSE) R

6431 932220595685 DIO SIG SM 1N4148WS-V (VISH) R

Item Nr.

LCD 37" - 50"

LCD 26" - 32"

PDP 42" - 50"

Decription

2612 319801741050 CER2 0603 Y5V 10V 1U COL

2613 319801741050 CER2 0603 Y5V 10V 1U COL

2616 202055200035 CER2 0603 X5R 6V3 2U2 PM10 R

2617 202055200035 CER2 0603 X5R 6V3 2U2 PM10 R

2619 319803024790 ELCAP SM 6V3 47U PM20 COL R

3615 319803101030 RST SM 0402 10K PM5 COL

3616 319803101020 RST SM 0402 1K PM5 COL

319803190010 RST SM 0402 JUMP. 0R05 COL

3617 319803101020 RST SM 0402 1K PM5 COL

3618 319803102230 RST SM 0402 22K PM5 COL

3619 319803101030 RST SM 0402 10K PM5 COL

3620 319803101030 RST SM 0402 10K PM5 COL

3623 319803104730 RST SM 0402 47K PM5 COL

3625 319803103320 RST SM 0402 3K3 PM5 COL

3627 319803102230 RST SM 0402 22K PM5 COL

3628 319803101030 RST SM 0402 10K PM5 COL

3629 319803102230 RST SM 0402 22K PM5 COL

3630 319803102220 RST SM 0402 2K2 PM5 COL

319803103310 RST SM 0402 330R PM5 COL

3631 319803102220 RST SM 0402 2K2 PM5 COL

319803103310 RST SM 0402 330R PM5 COL

3632 232270570569 RST SM 0402 RC31 56R PM5 R

3633 232270570569 RST SM 0402 RC31 56R PM5 R

4601 319802190030 RST SM 0603 JUMP. 0R05 COL

4602 319802190030 RST SM 0603 JUMP. 0R05 COL

4603 319802190030 RST SM 0603 JUMP. 0R05 COL

4606 319802190030 RST SM 0603 JUMP. 0R05 COL

4609 319802190030 RST SM 0603 JUMP. 0R05 COL

4610 319802190030 RST SM 0603 JUMP. 0R05 COL

4611 319802190030 RST SM 0603 JUMP. 0R05 COL

4612 319802190030 RST SM 0603 JUMP. 0R05 COL

4613 319802190030 RST SM 0603 JUMP. 0R05 COL

4614 319802190030 RST SM 0603 JUMP. 0R05 COL

4615 319802190030 RST SM 0603 JUMP. 0R05 COL

4618 319802190030 RST SM 0603 JUMP. 0R05 COL

4619 319802190030 RST SM 0603 JUMP. 0R05 COL

7603 319801042310 TRA SIG SM BC847BW (COL) R

7604 319801042310 TRA SIG SM BC847BW (COL) R

7607 319801042310 TRA SIG SM BC847BW (COL) R

Item Nr.

PDP - 42" - 50"

LCD 26" - 32"

LCD 37" - 42"

Description

2701 319803401010 CER1 0402 NP0 50V 100P COL

2702 319803571040 CER2 0402 Y5V 16V 100N COL

2706 319803041090 ELCAP SM 16V 10U PM20 COL R

2709 319803044790 ELCAP SM 16V 47U PM20 COL R

2710 202055200211 CER2 1210 X5R 16V 22U PM10 R

2711 202055200211 CER2 1210 X5R 16V 22U PM10 R

2717 319803571040 CER2 0402 Y5V 16V 100N COL

2718 319803571040 CER2 0402 Y5V 16V 100N COL

2719 319803571040 CER2 0402 Y5V 16V 100N COL

2720 319803501020 CER2 0402 X7R 50V 1N COL

2721 319803571040 CER2 0402 Y5V 16V 100N COL

2722 319803501020 CER2 0402 X7R 50V 1N COL

2723 319803574730 CER2 0402 Y5V 16V 47N COL

2724 319801631020 CER1 0603 NP0 25V 1N COL

2725 319801631020 CER1 0603 NP0 25V 1N COL

2726 202002100097 ELCAP SM SGV 16V 470U PM20 R

2727 319803521030 CER2 0402 X7R 16V 10N COL

2741 319801732240 CER2 0603 X7R 10V 220N COL

222224059872 CER2 0805 Y5V 10V 4U7 P8020 R

2752 319803044790 ELCAP SM 16V 47U PM20 COL R

3701 319803101030 RST SM 0402 10K PM5 COL

3702 319803101030 RST SM 0402 10K PM5 COL

3709 319803106820 RST SM 0402 6K8 PM5 COL

3718 232275061009 RST SM FUSE 1206 10R PM5 R

3719 319803106810 RST SM 0402 680R PM5 COL

3720 319802132280 RST SM 0603 2R2 PM5 COL

3721 319802132280 RST SM 0603 2R2 PM5 COL

3722 319803102720 RST SM 0402 2K7 PM5 COL

3723 319802151090 RST SM 0805 10R PM5 COL R

3724 319803101530 RST SM 0402 15K PM5 COL

3725 232270463302 RST SM 0603 RC22H 3K3 PM1 R

3726 319803101220 RST SM 0402 1K2 PM5 COL

3727 232270461002 RST SM 0603 RC22H 1K PM1 R

3740 319803101520 RST SM 0402 1K5 PM5 COL

3741 319803101520 RST SM 0402 1K5 PM5 COL

3742 319803101530 RST SM 0402 15K PM5 COL

3743 319803102230 RST SM 0402 22K PM5 COL

3750 319803102230 RST SM 0402 22K PM5 COL

3755 319803101030 RST SM 0402 10K PM5 COL

3758 319803101530 RST SM 0402 15K PM5 COL

3759 319803101230 RST SM 0402 12K PM5 COL

5700 242254945333 IND FXD 1206 EMI 100MHZ 120R R

5704 242254945333 IND FXD 1206 EMI 100MHZ 120R R

5709 242253594134 IND FXD SM 7032 10U PM20 R

5713 242253601218 IND FXD SM DRH104RNP 3U3 PM30

5717 242253600671 IND FXD SM 12575 10U PM20 R

5754 242253594134 IND FXD SM 7032 10U PM20 R

5756 242254945333 IND FXD 1206 EMI 100MHZ 120R R

5757 242254945333 IND FXD 1206 EMI 100MHZ 120R R

6717 319801010630 DIO SIG SM BAS316 (COL) R

6718 319801010720 DIO REC SS24 COL R

6740 934054857115 DIO REG SM PDZ8.2B (PHSE) R

6751 319801010710 DIO REC SS14 COL R

7708 932213916668 IC SM LF33CPT (ST00) R

7710 932218277668 IC SM L6910 (ST00) R

7711 932216070668 FET POW SM SI4936ADY-E3(VISH)R

7741 319801042310 TRA SIG SM BC847BW (COL) R

7742 319801042310 TRA SIG SM BC847BW (COL) R

7754 932221400668 FET POW SM SI2301BDS-E3(VISH)R

7755 319801044110 TRA SIG SM PDTC114ET (COL) R

7756 319801044110 TRA SIG SM PDTC114ET (COL) R

7758 932221214668 FET POW SM SI4423DY-E3 (VISH)R

G_16210_065.eps

190106
