Technical Specifications, Connections, and Chassis Overview
EN 5LC7.1E LA 1.
Figure 1-6 PWB/CBA locations (42” models)
H_16940_008.eps
050307
B
POWER SUPPLY UNIT
D
SIDE I/O PANEL
SMALL SIGNAL
BOARD
J
LED PANEL
E
CONTROL PANEL
