Mechanical Instructions
EN 9LC7.1E LA 4.
4. Mechanical Instructions
Index of this chapter:
4.1 Cable Dressing
4.2 Service Positions
4.3 Assy/Panel Removal
4.4 Set Re-assembly
Notes:
• Figures below can deviate slightly from the actual situation,
due to the different set executions.
• Follow the disassemble instructions in described order.
They apply to the 32” sets.
4.1 Cable Dressing
Figure 4-1 Cable dressing (32” models)
G_16860_064.eps
310107
