Alignments
EN 71LC7.1E LA 8.
Option Bit Overview
Below find an overview of the Option Codes on bit level.
Table 8-3 Option codes at bit level (OP1-OP4)
Option Byte & Bit Dec. Value Option Name Description
Byte OP1
Bit 7 (MSB) 128 Reserved Not Used (Reserved)
Bit 6 64 CHINA ON = SW is for CHINA only OFF = SW is for Non-China AP cluster
Bit 5 32 DTV_CHINA ON = DTV_CHINA will be available (Reserved) OFF = DTV_CHINA will not be available
Bit 4 16 DTV_EU ON = DTV will be available OFF = DTV will not be available
Bit 3 8 UK_PNP ON = UK PNP is available OFF = UK PNP is not available
Bit 2 4 VIRGIN_MODE ON = Virgin Mode (PNP) is available OFF = Virgin Mode (PNP) is not available
Bit 1 2 ACI ON = ACI is available OFF = ACI is not available
Bit 0 (LSB) 1 ATS ON = ATS is available OFF = ATS is not available
Total DEC Value
Byte OP2
Bit 7 (MSB) 128 1080P ON = 1080p is available OFF = 1080p is not available
Bit 6 64 LIGHT_SENSOR ON = Light Sensor is available OFF = Light Sensor is not available
Bit 5 32 AMBILIGHT ON = Ambilight Feature will be available OFF = Ambilight Feature will not be available
Bit 4 16 BACKLIGHT_DIMMING ON = Backlight Dimming is available OFF = Backlight Dimming is not available
Bit 3 8 HUE ON = Hue is available OFF = Hue is not available
Bit 2 4 2D3DCF ON = 3D Comb Filter is available OFF = 2D Comb Filter is available
Bit 1 2 WSSB ON = WSS is available OFF = WSS is not available
Bit 0 (LSB) 1 WIDE_SCREEN ON = TV is 16x9 set OFF = TV is 4x3 set
Total DEC Value
Byte OP3
Bit 7 (MSB) 128 CVI2 ON=CVI1 (YPbPr) (For ROW)
Bit 6 64 Reserved Not Used (Reserved)
Bit 5 32 Reserved Not Used (Reserved)
Bit 4 16 VCHIP ON = VChip is available OFF = VChip is not available
Bit 3 8 VIDEO_TEXT ON = Video-TXT is available OFF = Video-TXT is not available
Bit 2 4 STEREO_DBX ON = Stereo DBX detection is available (LATAM) OFF = Stereo DBX detection is not available
Bit 1 2 STEREO_NICAM_2CS ON = Stereo NICAM 2CS detection is available (EU/AP/China) OFF = Stereo NICAM 2CS
detection is not available
Bit 0 (LSB) 1 LIP_SYNC ON = Lip Sync is available OFF = Lip Sync is not available
Total DEC Value
Byte OP4
Bit 7 (MSB) 128 HDMI2 ON = HDMI2 is available OFF = HDMI2 is not available
Bit 6 64 HDMI1 ON = HDMI1 is available OFF = HDMI1 is not available
Bit 5 32 VGA ON = VGA is available OFF = VGA is not available
Bit 4 16 SVHS3 ON = SVHS3 is available OFF = SVHS3 is not available
Bit 3 8 AV3 ON = AV3 is available OFF = AV3 is not available
Bit 2 4 CVI ON = CVI is available OFF = CVI is not available
Bit 1 2 SVHS2 ON = SVHS2 is available OFF = SVHS2 is not available
Bit 0 (LSB) 1 AV2 ON = AV2 is available OFF = AV2 is not available
Total DEC Value
