Spare Parts List
EN 87LC7.1HE LA 10.
10. Spare Parts List
Sets Listed per Model Number (CTN)
26HF5445/10 (Alt. BOM 1&2)
0807 3139 137 01142 SW i_Board
0815 3139 127 09076 Main Software
0816 3139 127 09094 Main NVM Software
0821 3139 127 09103 HDMI-1 Software
0822 3139 127 09113 HDMI-2 Software
1004 (B1) 9322 234 13682 LC260WX2-SLB2
1004 (B2) 9322 249 37682 LCD V260B1-L03
1005 3139 128 78452 Power Supply Unit
1112 3139 268 08011 IR/LED assy [J]
1114 3139 268 05921 Keyboard Assy [E]
1182 3139 267 28591 i-Board assy [HC]
8002 3104 311 06951 Cable 2p3/180/2p
8520 3104 311 10701 Cable 12p/680/12p
8521 3104 311 12441 Cable 14p/220/14p
8735 3139 131 08511 Cable 04p/400 820/2ft
8C01 3139 131 08551 Cable 9p/180/9p Bk
8G51 3139 131 08282 LVDS 30p/180/30p
8H01 3104 311 07391 Cable 10p/220/10p
8H02 3139 171 00331 Cable 06p/280/06p
8H03 3139 131 04491 Cable 04p/220/04p
8H04 3104 311 07371 Cable 4p/340/4p
8M01 3104 311 12371 Cable 3p/80/3p Wh
8M20 3139 171 00321 Cable 14p/340+100/07p
8P11 3139 131 08581 Cable 8p/220/8p Bk
b
5213 2422 264 00605 Loudsp. 6Ω 15W FR
26HF7875/10 (Alt. BOM 1&2)
0176 3139 268 07501 LCD Clock assy
0807 3139 137 01142 SW i_Board
0815 3139 127 09076 Main Software
0816 3139 127 09094 Main NVM Software
0821 3139 127 09103 HDMI-1 Software
0822 3139 127 09113 HDMI-2 Software
1004 (B1) 9322 234 13682 LC260WX2-SLB2
1004 (B2) 9322 249 37682 LCD V260B1-L03
1005 3139 128 78452 Power Supply Unit
1112 3139 268 08011 IR/LED assy [J]
1114 3139 268 05921 Keyboard Assy [E]
1180 3139 268 08731 DC Converter assy [DC]
1181 3139 268 52332 System interf. assy [SI]
1182 3139 267 28591 i-Board assy [HC]
8002 3104 311 06951 Cable 2p3/180/2p
8208 3139 131 09061 Cable 05p/560/05p
8520 3104 311 10701 Cable 12p/680/12p
8521 3104 311 12441 Cable 14p/220/14p
8735 3139 131 08511 Cable 04p/400 820/2ft
8C01 3139 131 08551 Cable 9p/180/9p Bk
8G51 3139 131 08282 LVDS 30p/180/30p
8H01 3104 311 07391 Cable 10p/220/10p
8H02 3139 171 00331 Cable 06p/280/06p
8H03 3139 131 04491 Cable 04p/220/04p
8H04 3104 311 07371 Cable 4p/340/4p
8H05 3104 311 10821 Cable 12p/340/12p
8H06 3104 311 13081 Cable 6p/220/6p Wh
8H07 3139 131 05021 Cable 05p/120/05p
8H08 3139 131 09031 Cable 08p/140/08p
8M01 3104 311 12371 Cable 3p/80/3p Wh
8M20 3139 171 00321 Cable 14p/340+100/07p
8P11 3139 131 08581 Cable 8p/220/8p Bk
b
5213 2422 264 00605 Loudsp. 6Ω 15W FR
32HF5445/10
0807 3139 137 01142 SW i_Board
0815 3139 127 09076 Main Software
0816 3139 127 09094 Main NVM Software
0821 3139 127 09103 HDMI-1 Software
0822 3139 127 09113 HDMI-2 Software
1004 9322 249 06682 LCD T315XW02VD
1005 3139 128 78452 Power Supply Unit
1112 3139 268 08011 IR/LED assy [J]
1114 3139 268 05921 Keyboard Assy [E]
1182 3139 267 28591 i-Board assy [HC]
8002 3104 311 07121 Cable 2p3/220/Inlet
8521 3104 311 12441 Cable 14p/220/14p
8735 3139 131 08671 Cable 4p/480 1000/2ft
8C01 3139 131 08541 Cable 9p/220/9p Bk
8G51 3139 131 08282 LVDS 30p/180/30p
8H01 3104 157 02191 Cable 10p/340/10p Bk
8H02 3139 171 00341 Cable 06p/340/06p
8H03 3139 131 04491 Cable 04p/220/04p
8H04 3139 131 07041 Cable 4p/480/4p
8M01 3104 311 12371 Cable 3p/80/3p Wh
8M20 3139 171 00311 Cable 14p/480+140/07p
8P11 3139 131 08581 Cable 8p/220/8p Bk
b
5200 3139 268 53991 Speaker Assy
32HF7875/10
0176 3139 268 07501 LCD Clock assy
0807 3139 137 01142 SW i_Board
0815 3139 127 09076 Main Software
0816 3139 127 09094 Main NVM Software
0821 3139 127 09103 HDMI-1 Software
0822 3139 127 09113 HDMI-2 Software
1004 9322 249 06682 LCD T315XW02VD
1005 3139 128 78452 Power Supply Unit
1112 3139 268 08011 IR/LED assy [J]
1114 3139 268 05921 Keyboard Assy [E]
1180 3139 268 08731 DC Converter assy [DC]
1181 3139 268 52332 System interf. assy [SI]
1182 3139 267 28591 i-Board assy [HC]
8002 3104 311 07121 Cable 2p3/220/Inlet
8521 3104 311 12441 Cable 14p/220/14p
8735 3139 131 08671 Cable 4p/480 1000/2ft
8C01 3139 131 08541 Cable 9p/220/9p Bk
8G51 3139 131 08282 LVDS 30p/180/30p
8H01 3104 157 02191 Cable 10p/340/10p Bk
8H02 3139 171 00341 Cable 06p/340/06p
8H03 3139 131 04491 Cable 04p/220/04p
8H04 3139 131 07041 Cable 4p/480/4p
8H05 3139 110 28321 Cable 12p/400/12p Bk
8H06 3139 110 27861 Cable 06p/080/06p Bk
8H07 3139 131 05021 Cable 05p/120/05p
8H08 3139 131 09031 Cable 08p/140/08p
8M01 3104 311 12371 Cable 3p/80/3p Wh
8M20 3139 171 00311 Cable 14p/480+140/07p
8P11 3139 131 08581 Cable 8p/220/8p Bk
b
5200 3139 268 53991 Speaker Assy
42HF7845/10
0807 3139 137 01142 SW i_Board
0815 3139 127 09076 Main Software
0816 3139 127 09094 Main NVM Software
0821 3139 127 09103 HDMI-1 Software
0822 3139 127 09113 HDMI-2 Software
1004 9322 249 09682 LCD LC420WX5-SLD1
1005 3122 427 24573 PSU PLCD300P3
1112 3139 268 08011 IR/LED assy [J]
1114 3139 268 05921 Keyboard Assy [E]
1180 3139 268 08731 DC Converter assy [DC]
1181 3139 268 52332 System interf. assy [SI]
1182 3139 267 28591 i-Board assy [HC]
8002 3104 311 08071 Cable 2P3/140
8520 3104 311 08191 Cable 12p/1200/12p
8521 3104 311 12481 Cable 14p/400/14p Wh
8735 3139 131 08041 Cable 4p/560 820/2ft
8C01 3139 131 08521 Cable 9p/400/9p Bk
8G51 3139 131 08291 Cable 30p/280/30p Fi-x
8H01 3104 311 08821 Cable 10p/400/10p
8H02 3139 171 00351 Cable 06p/400/06p
8H03 3139 131 04381 Cable 04p/340/04p
8H04 3139 131 06281 Cable 04p/680/04p Bk
8H05 3104 311 10821 Cable 12p/340/12p
8H06 3139 110 27861 Cable 06p/080/06p Bk
8H07 3139 131 04351 Cable 05p/220/05p
8H08 3139 131 09021 Cable 08p/340/08p
8M01 3104 311 12371 Cable 3p/80/3p Wh
8M20 3139 171 00301 Cable 14p/560+280/07p
8P11 3139 131 08561 Cable 8p/400/8p Bk
b
5211 2422 264 00618 Loudsp. 6Ω 15W R
5212 2422 264 00617 Loudsp. 6Ω 15W L
Small Signal Board [B]
Various
1101 3139 147 19801 Tuner UV1318S/A IH -3
1102 9322 042 72682 SAW 38.9MHz K3953M
1103 2422 549 44341 SAW 38.9MHz K9656M
1104 2422 543 01386 Xtal 4MHz 20p
1201 2422 543 01133 Xtal 14.32MHz 20pF
1210 2422 549 45325 Bead 67Ω at 100MHz
1211 2422 549 45325 Bead 67Ω at 100MHz
1212 2422 549 45325 Bead 67Ω at 100MHz
1213 2422 549 45325 Bead 67Ω at 100MHz
1214 2422 549 45325 Bead 67Ω at 100MHz
1215 2422 549 45325 Bead 67Ω at 100MHz
1216 2422 549 45325 Bead 67Ω at 100MHz
1301 2422 543 01526 Xtal 10MHz 12p NX8045
1311 2422 025 18738 Connector 3p m
1312 2422 025 18734 Connector 11p m
1314 2422 025 18749 Connector 3p m
1411 2422 543 01461 Xtal 18.432MHz 12p
1504 2422 025 15682 21p (SCART)
1504 2422 025 20251 SCART V 21p F Bk
1506 2422 025 15682 21p (SCART)
1506 2422 025 20251 SCART V 21p F Bk
1525 2422 025 17931 Connector 5P m
1526 2422 025 18258 Connector 8p m
1601 2422 033 00563 Sock. 2p f Cinch/mdin Y
1603 2422 026 05647 Cinch 2P F 2L1
1615 2422 026 05894 Socket Cinch
1619 2422 025 17955 Connector 6P m
1735 2422 025 09406 Connector 4p m
1810 2422 033 00617 Socket HDMI
1811 2422 033 00617 Socket HDMI
1823 2422 543 01517 Xtal 28M322 18p NX5032
1900 2422 026 04734 Socket phone 3.5mm
1901 2422 025 17764 Connector 4p m
1C01 2422 025 10769 Connector 9p m
1G51 2422 025 18772 Connector 30p m
1M20 2422 025 09407 Connector 7p m
1P11 2422 025 08151 Connector 8p m
g
2112 2020 552 00211 22μF 10% 16V 1210
2112 2020 552 00343 22μF 10% 16V
2117 3198 017 31030 10nF 20% 50V 0603
2118 3198 017 31030 10nF 20% 50V 0603
2119 2020 552 96863 100nF 50V 0603
2120 2020 552 00211 22μF 10% 16V 1210
2120 2020 552 00343 22μF 10% 16V
2121 3198 016 31590 15pF 10% 50V 0603
2122 3198 016 31590 15pF 10% 50V 0603
2123 3198 017 31520 1.5nF 20% 50V 0603
2125 3198 017 44740 470nF 10V 0603
2126 3198 017 42240 220nF 16V Y5V 0603
2127 3198 016 32290 22pF 10% 50V 0603
2128 3198 017 31030 10nF 20% 50V 0603
2129 2020 552 00211 22μF 10% 16V 1210
2129 2020 552 00343 22μF 10% 16V
2130 3198 017 31030 10nF 20% 50V 0603
2131 2020 552 00211 22μF 10% 16V 1210
2131 2020 552 00343 22μF 10% 16V
2132 2020 552 00211 22μF 10% 16V 1210
2132 2020 552 00343 22μF 10% 16V
2133 3198 017 31030 10nF 20% 50V 0603
2136 3198 017 44740 470nF 10V 0603
2137 3198 017 31030 10nF 20% 50V 0603
2138 3198 017 31030 10nF 20% 50V 0603
2139 3198 016 33910 390pF 50V NP0 0603
2143 3198 017 31020 1nF 20% 50V 0603
2144 3198 017 31030 10nF 20% 50V 0603
2145 3198 017 31020 1nF 20% 50V 0603
2147 2238 786 19856 330nF 20% 160V 0603
2148 3198 017 31040 100nF 20% 50V 0603
2149 2020 552 00132 2.2μF 10% 10V
2151 3198 030 81090 10μF 20% 50V
2207 3198 017 31040 100nF 20% 50V 0603
2208 3198 030 41010 100μF 20% 16V
2209 3198 030 41010 100μF 20% 16V
2210 3198 017 31040 100nF 20% 50V 0603
2211 2020 552 00291 10μF 20% 6V3 0603
2212 3198 017 31040 100nF 20% 50V 0603
2213 3198 017 31040 100nF 20% 50V 0603
2214 3198 017 31040 100nF 20% 50V 0603
