ELECTRICAL PARTS LIST - KEY & VFD BOARD
DP200 9940 000 05469 VFD 35P 55x20
IC200 9965 000 41279 IC 28P EM78P447SAMY
IC200
9965 100 04636
IC 28P EM78P447SAMJ-G /12/05/58
IC201
9965 000 29614
IC 52P PT6311
IC201 9965 000 41280 IC 52P ET16311 VFD DRIVER /78
LD200 9940 000 05471 LED 2.94DIA BLUE
LD200
996510000591
LED D3 HI-BLUE /12/05/58
Q200 9965 000 41281 FET 2N7002 60V/115MA
Q201
9965 000 41281 FET 2N7002 60V/115MA
Q202 9965 000 41281 FET 2N7002 60V/115MA
Q203 9940 000 00915 XISTR NPN 2SC1623
Q204 9940 000 00915 XISTR NPN 2SC1623
Q205 9940 000 00915 XISTR NPN 2SC1623
Q206 9940 000 00921 XISTR PNP 2SA812 HFE:200-400
Q207 9940 000 00921 XISTR PNP 2SA812 HFE:200-400
Q208
9940 000 00921 XISTR PNP 2SA812 HFE:200-400
Q209 9940 000 05335 XISTR NPN TIP41C
Q210
! 9965 000 28742XISTR NPN 2SD882P
R249 9940 000 05474FUSEBLE RES 0.22R 1/4W 5%
SN200 9940 000 05472 IRT RECEIVER IRM-2638AF4
SN200
9965 100 04119
IR SENSOR 4.4~5.5V 38kHZ /12/05/58
T200 9940 000 05473OSC COIL 160UH 8% 796KHz
T201 9965 000 22303 OSC COIL REC OSC 3MH
TA200 9965 000 26952 TACT SW 2PIN 160GF 20MA 15V
TA201
9965 000 26952 TACT SW 2PIN 160GF 20MA 15V
TA202 9965 000 26952 TACT SW 2PIN 160GF 20MA 15V
TA203 9965 000 26952 TACT SW 2PIN 160GF 20MA 15V
TA204 9965 000 26952 TACT SW 2PIN 160GF 20MA 15V
TA205 9965 000 26952 TACT SW 2PIN 160GF 20MA 15V
TA206 9965 000 26952 TACT SW 2PIN 160GF 20MA 15V
TA207 9965 000 26952 TACT SW 2PIN 160GF 20MA 15V
TA208
9965 000 26952 TACT SW 2PIN 160GF 20MA 15V
TA209 9965 000 26952 TACT SW 2PIN 160GF 20MA 15V
TA210
9965 000 26952 TACT SW 2PIN 160GF 20MA 15V
TA211 9965 000 26952 TACT SW 2PIN 160GF 20MA 15V
TA212 9965 000 26952 TACT SW 2PIN 160GF 20MA 15V
Note: Only these parts mentioned in the list are
TA213 9965 000 26952 TACT SW 2PIN 160GF 20MA 15V
normal service parts.
XL200 9940 000 05352X'TAL 4.194304MHZ -/+10PPM
ZD200
9940 000 05476 ZENER; 5.6V 0.5W 5% MOT
ZD201 9940 000 05476 ZENER; 5.6V 0.5W 5% MOT
ZD202 9940 000 05476 ZENER; 5.6V 0.5W 5% MOT
ZD203 9965 000 41282 ZENER 21.52-22.63V 5% 0.5W
5-6 5-6
