Philips MCD139 - Power Board Electrical Parts List

ELECTRICAL PARTS LIST - POWER BOARD
BD901 9965 000 41295 BRIDGE RS406 4A 600V UL
C901 9965 000 41298 CAP.E 100UF 250V 105' 20%
C902 9965 000 41298 CAP.E 100UF 250V 105' 20%
C903 9965 000 18042 COND DISC 0.01UF 1KV 20%
C904 9965 000 18042 COND DISC 0.01UF 1KV 20%
C905 9965 000 27125 COND DISC 0.0022UF 1KV 20%
C907
! 9965 000 27115 CAP.SAFTY Y1 102PF 250V 20%
C908
! 9965 000 27115 CAP.SAFTY Y1 102PF 250V 20%
C909
! 9965 000 27115 CAP.SAFTY Y1 102PF 250V 20%
C909
! 9965 000 38398 CAP. SAFTY 152PF 250V 20% /12/05/58
C910
! 9965 000 27115 CAP.SAFTY Y1 102PF 250V 20%
C911 9940 000 05236 COND DISC 220PF 1KV 10%
C912 9940 000 05236 COND DISC 220PF 1KV 10%
C923
! 9940 000 05343 COND SAF. 0.22UF 275V 20%
C923
! 9965 100 04626 COND SAF. 0.47UF 275V 20% /12/05/58
C927
! 9965 000 27115 CAP.SAFTY Y1 102PF 250V 20%
C928
! 9940 000 05707 COND SAFTY 0.1UF 250V 20%
D901 9940 000 05459 DIODE STPR1020CT
D901 9965 000 41296 DIODE STPR1020CT 10A
D902 9940 000 00938 DIODE PR1507 1.5A 1000V
D903 9940 000 00941 DIODE HER104 1A 300V 50NS
D904 9965 000 41297 DIODE SB560 CTC 5A 60
F901
! 9965 000 17388 FUSE 3.15A 250V SLOW
IC901 9940 000 05462 IC 6P TOP247Y PWM SWITCH
IC901 9965 100 04628
IC 6P TOP247YN POWER INT /12/05/58
IC902 9940 000 00946 OPTICAL SENSOR 4P
IC903 9965 000 29312 IC 3 PIN TL431 TO-92 CHANG JI
L903 9940 000 05457AC FILTER ET-24 D0.45 30MH
NTC901 9940 000 05232 THERMISTOR NTC 5R 5A
T901
! 9965 000 40980 TRASFO. ER-28 6 8PIN
TVR901 9965 000 32754 THERMIST 50A 561V D13.5XT4.9MM
TVR901 9965 100 04625
VARISTORS 50A 560V /12/05/58
Note: Only these parts mentioned in the list are
normal service parts.
