Philips MCD149 - Factory Part List - Resistors (Continued); Resistor Values and Locations

Level Item Component Desc Unit Qty Location AppForm ChangeNo MatProInd
..2 0030 8910-060400100 KEY PWB ASSEMBLY OF MCM119/12 SET 1.000
...3 0010 1121-102081020 CH-CAP, CER 1000PF50V+/-5%0603 PC 1.000 C208
...3 0020 1221-471062020 CH-RES,470R1/16W+/-5%0603 PC 1.000 R214
...3 0030 1221-182062020 CH-RES,1.8K1/16W+/-5%0603 PC 1.000 R215
...3 0040 1221-272062020 CH-RES,2.7K1/16W+/-5%0603 PC 1.000 R216
...3 0050 1221-332062020 CH-RES,3.3K1/16W+/-5%0603 PC 1.000 R217
...3 0060 1221-392062020 CH-RES,3.9K1/16W+/-5%0603 PC 1.000 R218
...3 0070 2721-272030010 CH-FB,2700OHM+/-25% 0805 SZ2012K272T(LF). PC 2.000 L209,L210 FA040575
...3 0080 3302-010115000 SWITCH TACT TS-03-BS-180G 5MM PC 6.000
SW209,SW210,SW211,SW212,SW213,SW
214
FA060326
...3 0090 3501-020122010
HOUSING 2PIN P=2.0MM L=120MM AWG#30 UL1571 SINGLE PLUG
(RED/BLACK)
PC 1.000 CN202 FAP061484 T0608084
...3 0095 3501-020122020
HOUSING 2PIN P=2.0MM L=120MM AWG#30 UL1007 SINGLE PLUG
(RED/BLACK)
PC 1.000 CN202 T0608084
...3 0100 3701-011900210 PWB 141x161x1.6MM/5 94V0 MCM119-02 (KEY). PC 1.000 FAP061558
..2 0040 8931-071000100 USB PWB ASSEMBLY OF MCD149/EU SET 1.000
...3 0010 1121-104082020 CH-CAP, CER0.1UF50V+/-10%0603 PC 1.000 C209
...3 0020 3106-120611000 FFC CONNECTOR 6P PH=1.25MM 90 DEGREE PC 1.0
00 CON201 FAP061413
...3 0030 3209-040200000 USB JACK USB-1400A 4P PC 1.000 JK201 FA051716
...3 0040 3601-106000010 CH-MULT.VAR.EZJZ1V120KA 10.6-15.4V 0603 PC
2.000 M201,M202 FAP061433
...3 0050 3702-014900530 USB PWB D.S. FR4 195x110x1.2MM/20 MCD149-05 V1.0 PC 1.000
..2 0050 8905-071000100 AMPLIFIER PWB ASSEMBLY OF MCD149. SET 1.000
...3 0010 1112-337083140 CAP ELECT,330UF50V+/-20%10x16 PC 1.000 C150
...3 0020 1121-221082020 CH-CAP, CER 220PF50V+/-10%0603 PC 14.000
C113,C116,C124,C125,C126,C127,C1
32,C144,C155,C161,C170,C171,C172
,
C173
...3 0030 1121-561081020 CH-CAP, CER560PF50V+/-5%0603 PC 4.000 C184,C
185,C186,C187
...3 0040 1121-103082020 CH-CAP, CER0.01UF50V+/-10%0603 PC 5.000 C108
,C110,C135,C138,C200
...3 0050 1121-153082020 CH-CAP, CER15NF50V+/-10%0603 PC 4.000 C133,C136,C162,C164
...3 0060 1121-333082020 CH-CAP, CER0.033UF50V+/-10%0603 PC 4.000 C114,C115,C117,C118
...3 0070 1121-473082020 CH-CAP, CER0.047UF50V+/-10%0603 PC 3.000 C145,C148,C180
...3 0080 1121-683082020 CH-CAP,0.068UF50V+/-10%0603 PC 1.000 C179
...3 0090 1121-104082020 CH-CAP, CER0.1UF50V+/-10%0603 PC 35.000
C101,C103,C107,C109,C111,C112,C1
19,C120,C121,C129,C131,C134,C139
,C140,C141,C158,C159,C160,C163,C
174,C175,C182,C183,C188,C189,C19
0,C191,C192,C193,C194,C195,C196,
C197
,
C198
,
C199
...3 0100 1121-334051020 CH-CAP, CER0.33UF 16V+/-5%0603 PC 1.000 C146
...3 0110 1121-105082020 CH-CAP, CER 1UF50V+/-10%0603 PC 4.000 C142,C
143,C156,C157
...3 0120 1132-106053060 CAP ELECT, 10UF 16V +/-20% 5X11 TAPING PC 7
.000
C149,C152,C153,C168,C169,C201,C2
02
...3 0130 1132-476053060 CAP ELECT, 47UF 16V +/-20% 5X11 TAPING PC 3.000 C123,C151,C177
...3 0140 1132-476073070
CAP ELEC KM 47UF 35V +/-20% 105C RAD ST5 6x11MM
EKM476M1VD11TCSA TAPING
PC 2.000 C102,C104
...3 0150 1132-476083100 CAP ELECT, 47UF 50V +/-20% 6.3X11 TAPING P
C 2.000 C137,C154
...3 0160 1132-107053060 CAP ELECT, 100UF 16V +/-20% 5X11 TAPING PC 5.000 C100,C122,C176,C178,C181
...3 0170 1132-477073140
CAP, ELECT, 470UF 35V +/-20% 10X16mm 105DEGREE (SHORT
LEGS)
PC 2.000 C105,C106
...3 0180 1138-105091000
CAP METALLIZED POLYESTER FILM 1.0uF 63V +/-5% CL21X
TAPING
PC 4.000 C128,C130,C165,C166 FAP070607 T0707042
...3 0190 1211-047072000 RES,4.7R1W+/-5% PC 1.000 R201
...3 0200 1214-103006000 THERMISTOR RES, NTC FH-CWF103H3950FA-165E
10K +/-3% PC 1.000 MOUNTATHEATSINK
...3 0210 1221-000062020 CH-RES,0 OHM1/16W+/-5%0603 PC 1.000 R151
...3 0220 1221-047022050 CH-RES,4.7R1/4W+/-5%1206 PC 4.000 R184,R185,R186,R187
...3 0230 1221-100022050 CH-RES,10R1/4W+/-5%1206 PC 2.000 R101,R102
...3 0240 1221-100062020 CH-RES,10R1/16W+/-5%0603 PC 5.000 R113,R114,R149,R169,R170
...3 0250 1221-220022050 CH-RES,22R1/4W+/-5%1206 PC 5.000 R115,R116,R154,R168,R171
...3 0260 1221-101062020 CH-RES,100R1/16W+/-5%0603 PC 2.000 R124,R125
...3 0280 1221-151062020 CH-RES,150R1/16W+/-5%0603 PC 1.000 R137
...3 0290 1221-471062020 CH-RES,470R1/16W+/-5%0603 PC 2.000 R176,R188
...3 0300 1221-561062020 CH-RES,560R1/16W+/-5%0603 PC 1.000 R136
...3 0310 1221-681062020 CH-RES,680R1/16W+/-5%0603 PC 2.000 R138,R139
...3 0320 1221-681022050 CH-RES,680R1/4W+/-5%1206 PC 2.000 R157,R158
...3 0330 1221-102062020 CH-RES,1K1/16W+/-5%0603 PC 4.000 R142,R145,R150,R156
...3 0340 1221-222062020 CH-RES,2.2K1/16W+/-5%0603 PC 8.000
R103,R160,R164,R165,R177,R189,R1
90
...3 0350 1221-272062020 CH-RES,2.7K1/16W+/-5%0603 PC 1.000 R141
...3 0360 1221-472062020 CH-RES,4.7K1/16W+/-5%0603 PC 4.000 R179,R180,R192,R193
...3 0370 1221-562062020 CH-RES,5.6K1/16W+/-5%0603 PC 11.000
R105,R106,R107,R108,R109,R110,R1
11
,
R120
,
R121
,
R122
,
R123
...3 0380 1221-822062020 CH-RES,8.2K1/16W+/-5%0603 PC 2.000 R161,R162
...3 0390 1221-103062020 CH-RES,10K1/16W+/-5%0603 PC 2.000 R152,R163
...3 0400 1221-203062020 CH-RES,20K1/16W+/-5%0603 PC 1.000 R143
12-5
FACTORY PARTLIST
