Philips MCD149 - Factory Part List - Components; Transistors, ICs, and Connectors

Level Item Component Desc Unit Qty Location AppForm ChangeNo MatProInd
...3 0410 1221-223062020 CH-RES,22K1/16W+/-5%0603 PC 3.000 R131,R132,
R167
...3 0420 1221-303062020 CH-RES,30K1/16W+/-5%0603 PC 2.000 R112,R119
...3 0430 1221-473062020 CH-RES,47K1/16W+/-5%0603 PC 4.000 R104,R140,
R147,R148
...3 0440 1221-244062020 CH-RES,240K1/16W+/-5%0603 PC 1.000 R166
...3 0450 1221-105062020 CH-RES,1M1/16W+/-5%0603 PC 5.000 R134,R135,R146,R182,R183
...3 0460 1313-000560000 ZENER DIODE 5.6V 1/2W PC 1.000 ZD101 FAP060929
...3 0470 1313-001200010 ZENER DIODE 12V 1/2W TAPING. PC 3.000 ZD102,ZD103,ZD104 FAP061320
...3 0480 1321-041480020 CH-DIODE RLS4148 LL-34 PC 1.000 D103
FA060300,
FAP060547
...3 0490 1411-385500000 TRANSISTOR,PNP 3CA8550 hFE=120-220 TO-92 P
C 1.000 Q103 FA050161
...3 0500 1421-385500000 CH-TRANSISTOR PNP 3CA8550M SOT-23 PC 3.000 Q
106,Q107,Q108 FAP070302
...3 0501 1421-085500010 CH-TRANSISTOR PNP SS8550LT1 SOT-23 PC 3.000
Q106,Q107,Q108 FAR070606
...3 0520 1422-380500000 CH-TR. NPN 3DA8050 hFE=120-220 SOT-23 PC 6.
000 Q101,Q102,Q104,Q105,Q109,Q110 FAP060921
...3 0530 1502-004558030 IC, AZ4558 OPERATIONALL AMP. CD PC 2.000 U10
3,U104 FAP060499
...3 0540 1502-008922000 IC TDA8922BTH 2x50W CLASS-D POWER AMPLIFI
ER HSOP24 PC 2.000 U101,U102
...3 0550 1614-220022000 CHOKE COIL 22uH 15% 100KHz 0.1R 8080PH-03
-220K PC 4.000 L103,L104,L105,L106
...3 0560 2105-000000050 EMI FILTER BEAD RH3.5x8x0.8mm PC 2.000 L101,
L102 FAP070567
...3 0570 3101-200221010 HEADER 2PIN 2.0MM STRAIGHT PC 1.000 CN102
FA030083,
FAP061602
...3 0580 3101-250212010 HEADER JS-1001R-02 2PIN 2.5MM 90 DEGREE (BLACK) PC 1.000 CN101 FAP061593
...3 0590 3101-390221000 HEADER 2PIN P=3.96MM STRAIGHT PC 1.000 CN104 FAP061483
...3 0600 3112-221516000
D-SUB CONNECTOR 15PIN HF-051188-001-000 P=2.29MM
90DEGREE
PC 1.000 CN106 FAP061594
...3 0605 3401-000000010 SP TERMINAL MSP-134V-05 LF PC 1.000 CN103 FA030245 T0707012
...3 0607 3501-080203900 HOUSING 8PIN P=3.96MM L=200MM AWG#18 SINGLE PLUG PC 1.000 CN105TOSMPS T0707012
...3 0610 3702-014900230 AMPLIFIER PWB D.S. FR4 120X87X1.2MM/2 MCD149-02 V1.0 PC 1.000
...3 0620 6023-230100100 SCREW, M B B3X10B (TOYO:A023010002) PC 3.00
0 3-HEATSINKTDA8922D+PCB FA051216
...3 0630 6600-071000100 HEAT SINK TDA8922D PC 1.000
...3 0640 6306-060400100 BRACKET MAIN BOARD (SPTE T=0.5MM) PC 1.000 F
AP061487
..2 0060 8916-071000100 SCART PWB ASSEMBLY OF MCD149/EU. SET 1.000
...3 0010 1211-101022000 RES,100R1/4W+/-5% PC 3.000 R3,R7,R9
...3 0020 1211-331022000 RES,330R1/4W+/-5%. PC 1.000 R4
...3 0030 1121-391082020 CH-CAP, CER390PF50V+/-10%0603 PC 2.000 C8,C1
1
...3 0040 1121-104082020 CH-CAP, CER0.1UF50V+/-10%0603 PC 2.000 C1,C2
...3 0050 1132-106053060 CAP ELECT, 10UF 16V +/-20% 5X11 TAPING PC 1
.000 EC1
...3 0060 1132-107053060 CAP ELECT, 100UF 16V +/-20% 5X11 TAPING PC 1.000 EC2
...3 0070 1221-000062020 CH-RES,0 OHM1/16W+/-5%0603 PC 1.000 R12
...3 0080 1221-331062020 CH-RES,330R1/16W+/-5%0603 PC 2.000 R17,R18
...3 0090 1221-561022050 CH-RES,560R1/4W+/-5%1206 PC 1.000 R1
...3 0100 1221-681062020 CH-RES,680R1/16W+/-5%0603 PC 1.000 R10
...3 0110 1221-102062020 CH-RES,1K1/16W+/-5%0603 PC 1.000 R5
...3 0120 1221-103062020 CH-RES,10K1/16W+/-5%0603 PC 6.000 R2,R6,R8,R11,R15,R16
...3 0130 1311-140070000 DIODE RECT 1N4007 1A/1000V DO41. PC 1.000 D1 FAP070564
...3 0140 1323-000510050 CH-ZENER DIODE MM1Z5V1ST(4N) SOD-123 PC 7.000 Z1,Z2,Z3,Z6,Z7,Z12,Z13 FAP061252
...3 0150 1421-385500000 CH-TRANSISTOR PNP 3CA8550M SOT-23 PC 1.000 Q
4 FAP070302
...3 0160 1422-380500000 CH-TR. NPN 3DA8050 hFE=120-220 SOT-23 PC 3.000 Q1,Q2,Q3 FAP060921
...3 0170 2721-471020000 CH-FERRITE BEAD 470 OHM +/-25% 100MHz 0603 PC 3.000 L1,LA1,LA2
CAP060307
FAP070118
...3 0180 3005-000000000 JUMPER WIRE PC 2.000 SW1,SW2 L
...3 0190 3107-121511000 FPC CONNECTOR 15P PH=1.25MM 90DEGREE WHIT
E PC 1.000 J1 FAP070323
...3 0200 3207-210100010 JACK SCART CS-109 PC 1.000 SC1 FA051357
...3 0210 3701-014900320 SCART PWB S.S. 94HB 161x80x1.6MM/4 MCD149-03 V1.0 PC 1.000
..2 0070 8933-071000100 AC SOCKET PWB ASSEMBLY OF MCD149 SET 1.000
...3 0010 3110-000000030
AC POWER SOCKET 2PIN TC08-275-11 2.5A/250V 90 DEGREE
BLACK
PC 1.000 JK201 FA050708
...3 0015 3501-020107900 HOUSING 2PIN P=7.92MM L=200MM AWG#22 SINGLE PLUG PC 1.000 CN201TOSMPS T0707012
...3 0020 3701-014900610 AC PWB S.S. 94V0 120x120x1.6MM/8 MCD149--06 V1.0 PC 1.000
.1 0020 8900-071000200 ELECTRICAL ENCASING ASSY. OF MCD149/12 SET 1.
000
..2 0010 3801-000000160 TUNER MODULE KST-MT004FS1-6 (EUR). PC 1.000
..2 0020 3801-000000170 SMPS MODULE, FOR MCD149. PC 1.000
..2 0030 4405-120031300 DVD MECHANISM KHM-313AHC PC 1.000 FAP060526
..2 0040
8028-000000900 COOLING FAN DF125015SL 50X50X15MM
PC 1.000 FAP061532
..2 0050 3002-240190900 FFC CABLE 24PIN P=0.5MM L=190MM WHITE PC 1.000 CND004TOLOADER
FAP070265
FAP070741
T0707012
..2 0060 3502-060152000 HOUSING, 6P P=2.0MM AWG#30 L=150MM PLUG TO PLUG PC 1.000 CND003TOLOADER T0707012
..2 0070 3002-210110900 FFC CABLE 21P P=1.25MM L=110MM C TYPE WHITE PC 1.000 CON3TOCON802 FA060016 T0707012
..2 0080 3002-100300900 FFC CABLE 10P P=1.25MM L=300MM C TYPE WHITE PC 1.000 CON301TOTUNER T0707012
12-6
FACTORY PARTLIST
