Philips MCD196 - Mechanical Partslist

10 - 1
MECHANICAL PARTSLIST
1 996510001386 VOL KNOB
2 996510001385 DISPLAY LENS
3 996510001372 FRONT CABINET
4 996510001395 SPRING CASSETTE KEY DOOR
5 996510001384 CASS KEY DOOR
6 996510001394 SPRING CASSETTE DOOR
7 996510001376 CASSETTE DOOR
9 996510001388 POWER KEY(4KEY)
10 996510001391 POWER LIGHT GUIDE
11 996510001387 CONTROL KEYS(7KEY)
13 996510001377 CASS PAUSE KEY
13 996510001378 CASS STOP/OPEN KEY
13 996510001379 CASS SEARCH BACK KEY
13 996510001380 CASS SEARCH FRONT KEY
13 996510001381 CASS PLAY KEY
13 996510001382 CASS RECORD KEY
14 996510001383 BRACKET CASS KEY
15 996510001398 CASSETTE DECK CS-21SC-820T.
20 996510001390 LCD LIGHT GUIDE
21 996510001389 LCD BRACKET
24 996510001374 CD DOOR
25 996510001393 SPRING DOOR CD
26 996510001375 CD TRAY -/98/79
27 994000001664 DAMPER GEAR ASSEMBLY
28 9965100
18012 DVD MECHANISM KHM-313AHD
29 994000002737 CD DAMPER 1278 IIR BLK 38DEG
30 996510001392 COVER DUST FOR DVD DECK
31 996510001362 SERVO AND MPEG PWB ASSEMBLY
39 996510001373 REAR CABINET -/79/93/58
39 996510001461 REAR CABINET -/98
40 996510001396 RUBBER FOOT (10X10X4MM)
T601(36) 996510001399 POWER TRANSFORMER AC120/240V
994000001599 CD DOOR SW DLS-02-W-1 1P1T
996510001400 POWER CORD SAA H03VVH2-F 7.5A -/79
996510001462 POWER CORD H03VVH2-F VDE 2.5A -/98
ACCESSORIES
S3 996510001401 REMOTE CONTROL "PHILIPS"
S4 996510001402 SPEAKER BOX (LEFT)5W -/79
S4 996510001463 SPEAKER BOX (LEFT)5W -/98
S5 994000002597 RCA CABLE VIDEO (YELLOW)
S6 994000002598 RCA CABLE AUDIO (RED/WHITE)
S7 996510000306 AM LOOP ANT 18.1uH 8T
S8 996510000308 FM ANT WIRE 75R L1.0M
Note: Only these parts mentioned in the list are
normal service parts.
!
!
!
996510001987 POWER CORD LINE CCC 6A 250V -/93
S4 996510001988 SPEAKER BOX (LEFT)5W -/93
26 996510001983 CD TRAY -/93/58
