Philips MCD196 - Electrical Partslist

11 - 1
ELECTRICAL PARTSLIST
MAIN PWB ASSEMBLY
996510001358 FFC CABLE 21PIN L=150MM D TYPE
996510001359 FFC CABLE 10P L=200MM C TYPE
994000003329 FFC CABLE 24PIN PH=0.5MM L=134
996510001360 TUNER MODULE ENG06835QF.
FS501 996510001351 FUSE PTU 3.15A 250V "VDE"
FS502 994000003326 FUSE 2.5A 250V
IC201 996510001347 IC ET2314 SOUND SO28
IC204 996500041702 IC, AZ4558 OPERATIONALL
IC401 996510001348 IC POWER AMPLIFIER TFA9842BJ.
IC501 996500041730 IC TD1501 TO220B-5L 5V 3A 150K
IC502 996510001350 IC LM78L05 3-TERMINAL TO-92
IC801 996510001349 IC,AN7323 PREAMPLIFIERSETTE
JK101 996510001356 JACK S-VIDEO MDJ-202-9-4
JK201 996510001352 JACK 3.5MM STEREO
JK202 996510001353 3.5MM JACKS STEREO
JK203 996510001355 RCA JACK RCA-213P-15
JK204 996510001354 RCA JACK RCA-213/PB-081
JK401 994000001619 SP TERMINAL MSP-134V-05
Q205 996500041699 CH-TRANS. DTA114YKA SMT3
Q210 996500041727 TRANS. 2SA1037AK PNP SMT3
Q301 994000005652 TRANSISTOR PBSS5140S
Q505 996500041727 TRANS. 2SA1037AK PNP SMT3
Q509 996500041699 CH-TRANS. DTA114YKA SMT3
Q510 996500041725 TRANS. 2SB1370PNP TO-220FP
Q511 996500041726 TRANS. 2SC5343 NPN TO-92
QC801 994000005652 TRANSISTOR PBSS5140S
QC803 994000005653 CH-TRANSISTOR PBSS4140T
SWA801 996510001357 REC SWITCH 18PIN 6P2T 50MM
TC801 996500041709 IFT 049K10668 TYPE 7CDA BLACK
996510001346 MAIN PWB ASSEMBLY -/79/93/58
996510001458 MAIN PWB ASSEMBLY -/98
AC POWER PWB ASSEMBL
Y
994000004243 FUSE PTU 1A 250V 3.9X10.5MM
996510001361 AC POWER PWB ASSEMBLY -/79/93/58
996510001459 AC POWER PWB ASSEMBLY -/98
!
!
!
