Philips MCD705 - Page 34

13 - 2
IC11
IC7
IC8
- COILS & FILTERS -
XT301
XT302
CF2
CF1
T1
T2
T3
T4
T5
T7
- MISCELLANEOUS -
X1
JACK1
ENCODER801
S1
SPK1
SW901
F301
F302
CN10
JACK1
Note: Only these parts mentioned in the list are
normal service parts.
9940 000 03427 IC NE008
9940 000 03428 IC PT2322
9940 000 03429 IC 4558
9940 000 03453 CERAMIC FILTER CRB 700KHz
9940 000 03454 CERMIC FILTER FREQUENCY 600KHz
9940 000 03153 CERMIC FILTER FREQUENCY 10.7MHz
9940 000 03153 CERMIC FILTER FREQUENCY 10.7MHz
9940 000 03446 I.F.T. COIL 44023
9940 000 03447 I.F.T. COIL 20591
9940 000 03447 I.F.T. COIL 20591
9940 000 03448 I.F.T. COIL 20382
9940 000 03449 I.F.T. COIL 44108
9940 000 03451 I.F.T. COIL 43462
9940 000 03452 QUARTZ CRYSTAL 75KHz

9940 000 02528 4PINS RCA SOCKET
9940 000 02535 VOLUME CODER ED-1612-00-F15
9940 000 02542 IR SENSOR
9940 000 03431 5.1 SPEAKER JACK 6PZ-1
9940 000 03432 LIGHT TOUCH SWITCH
!
9940 000 03433 FUSE F6.3AL250V
!
9940 000 03433 FUSE F6.3AL250V
9940 000 03434 PIN CONNECTOR 40PINS 
9940 000 03435 ANT. LEADING-OUT JACK
ELETRICAL PARTSLIST - AMP PART
