13 - 3
- DIODES -
BD201 9940 000 02521 THYRISTOR RS406
D210 9940 000 02544 RECTIFIER DIODE IN5822
DZ201 9940 000 03407 ZENER DIODE 3.3V
DZ202 9940 000 03408 ZENER DIODE 27V
- TRANSISTORS -
Q201 9940 000 02519 TRANSISTOR 8550C
Q202 9940 000 02519 TRANSISTOR 8550C
Q206 9940 000 02519 TRANSISTOR 8550C
Q208 9940 000 02519 TRANSISTOR 8550C
Q203 9940 000 02518 TRANSISTOR 8050C
Q204 9940 000 02518 TRANSISTOR 8050C
Q207 9940 000 02518 TRANSISTOR 8050C
Q209 9940 000 02518 TRANSISTOR 8050C
Q210 9940 000 02518 TRANSISTOR 8050C
Q205 9940 000 02545 TRRANSISTOR 9014C
- IC -
IC202 9940 000 02547 IC AT24C02-PC27
IC203 9940 000 03162 CPU U252
IC205 9940 000 03411 IC D4558/RC4558
IC207 9940 000 02548 IC LM7805/LM340T5 7805
IC208 9940 000 02546 IC YD2576-ADJ
IC601 9940 000 02539 IC PT6311 / SC16311 / CD16311
- MISCELLANEOUS -
X201 9940 000 03152 CERMIC FILTER FREQUENCY 4.19MHZ
X202 9940 000 02551 CRYSTAL OSC FREQ.32.768 KHz
F201
!
9940 000 02529 FUSE F2AL250V
F209
!
9940 000 03412 FUSE F1.5A/125V
VFD701 9940 000 03413 VFD DISPLAY
RCA204 9940 000 03414 RCA SOCKET
SW601 9940 000 02543 LIGHT TOUCH SWITCH
SW602 9940 000 02543 LIGHT TOUCH SWITCH
SW603 9940 000 02543 LIGHT TOUCH SWITCH
SW604 9940 000 02543 LIGHT TOUCH SWITCH
SW605 9940 000 02543 LIGHT TOUCH SWITCH
SW606 9940 000 02543 LIGHT TOUCH SWITCH
SW607 9940 000 02543 LIGHT TOUCH SWITCH
SW608 9940 000 02543 LIGHT TOUCH SWITCH
JACK1301 9940 000 02556 OPTICAL & COAXIAL TERMINAL SOCKET
JACK202 9940 000 02553 3PINS RCA SOCKET(R/B/G)
CN210 9940 000 03415 PIN CONNECOTR 34PINS
JACK4 9940 000 03416 RCA SOCKET+S VIDEO
Note: Only these parts mentioned in the list are
normal service parts.
ELETRICAL PARTSLIST - DVD PART
