Philips MCD716 - Factory Partlist

LOCATION DESCRIPTION
MCD716/12 DVD UNIT PARTS ASS'Y
D111 MCD716 DISPLAY BOARD ASS'Y
R603 CARBON FILM RESISTOR 4.7 1/2W J-52
R604 CARBON FILM RESISTOR 4.7 1/2W J-52
R609 CARBON FILM RESISTOR 10K 1/8W J-52
R610 CARBON FILM RESISTOR 10K 1/8W J-52
C603 CARBON FILM RESISTOR 10K 1/8W J-52
C609 CARBON FILM RESISTOR 10K 1/8W J-52
R605 CARBON FILM RESISTOR 33K 1/8W J-52
R606 CARBON FILM RESISTOR 33K 1/8W J-52
R607 CARBON FILM RESISTOR 33K 1/8W J-52
R608 CARBON FILM RESISTOR 33K 1/8W J-52
R613 CARBON FILM RESISTOR 470 1/8W J-52
R615 CARBON FILM RESISTOR 470 1/8W J-52
R601 CARBON FILM RESISTOR 4.7K 1/8W J-52
R602 CARBON FILM RESISTOR 47K 1/8W J-52
C602 CERAMIC CAP. 104P 50V K-5
C604 CERAMIC CAP. 104P 50V K-5
C601 ELCTROLYTIC CAP.47u 16V L-5 5X11
D602 DIODE 4148-52
D603 DIODE 4148-52
IC601 IC PT6311/SC16311/CD16311
SW602 LIGHT TOUCH SWITCH TC103 6X6X5 170G
SW603 LIGHT TOUCH SWITCH TC103 6X6X5 170G
SW604 LIGHT TOUCH SWITCH TC103 6X6X5 170G
SW605 LIGHT TOUCH SWITCH TC103 6X6X5 170G
SW606 LIGHT TOUCH SWITCH TC103 6X6X5 170G
SW607 LIGHT TOUCH SWITCH TC103 6X6X5 170G
SW608 LIGHT TOUCH SWITCH TC103 6X6X5 170G
CN603 PIN S CONNECTOR 2.0/2P
CN604 PIN S CONNECTOR 2.0/2P
VFD701 VFD DISPLAY NE-705D-2.GB
PCB MCD716-01A1 03201 VFD DISPLAY
BLACK SPONGE 30X15X1 40°
BLACK SPONGE 25X10X1 40°
28WIRE 330 2.0/12PX1
D109 MCD716 USB LAMP BOARD ASS'Y
LED201 LED ĭ3 3B4SCB01 (BLUE)
26 WIRE 60 2.0/2PX1
MCD716-17A1 USB LAMP PCB
D134 MCD716 TOP COVER LAMP BOARD ASS'Y
R904 CHIP RESISTOR 680 1/4W J (1206)
R905 CHIP RESISTOR 680 1/4W J (1206)
LED1103 LED ĭ3 3B4SCB01 (BLUE)
LED1104 LED ĭ3 3B4SCB01 (BLUE)
35-MCD716-11A1 TOP COVER LAMPPCB
D132 MCD728 TOP COVER 2(ABS BLACK)
28 SINGLE WIRE 150 2.0/2PX1
28WIRE 190 2P
D133 MCD716 TOP COVER LAMP BOARD ASS'Y
R906 CHIP RESISTOR 680 1/4W J (1206)
R907 CHIP RESISTOR 680 1/4W J (1206)
LED1100 LED ĭ3 3B4SCB01 (BLUE)
LED1101 LED ĭ3 3B4SCB01 (BLUE)
35-MCD716-11A2 TOP COVER LAMP PCB
D134 MCD716 TOP COVER LAMP BOARD3 ASS'Y
R903 CHIP RESISTOR 680 1/4W J (1206)
R909 CHIP RESISTOR 680 1/4W J (1206)
LED1200 LED ĭ3 3B4SCB01 (BLUE)
LED1201 LED ĭ3 3B4SCB01 (BLUE)
35-MCD716-12A1 TOP COVER LAMP PCB
D110 MCD716 USB BOARD ASS'Y
JACK1601 USB JACK A-TYPE 4 P FEmALE 90°DIP TYPE
26 SHIELD WIRE 240 2.0/4PX1 2.0/4PX1
15-1
FACTORY PARTLIST
