Philips MCD716 - Page 38

MCD716-16A1 USB PCB
D127 MCD716 SCART BOARD ASS'Y
R1506 CARBON FILM RESISTOR 100 1/8W J-52
R1507 CARBON FILM RESISTOR 100 1/8W J-52
R1504 CARBON FILM RESISTOR 10K 1/8W J-52
R1505 CARBON FILM RESISTOR 10K 1/8W J-52
28WIRE 120 2.0/10PX1 2.0/10PX1
JP1501 21PINS SOCKET CS-121/SCART-113
35-MCD716-15A1 SCART PCB
JP1 BARE WIRE ĭ0.6X40mm (375m=1kG)
D126 MCD716 AUX BOARD ASS'Y
R1800 CARBON FILM RESISTOR 10K 1/8W J-52
R1802 CARBON FILM RESISTOR 10K 1/8W J-52
J1800 RCA SOCKET 2P AV2-8.4-14 RED/WHITE
26 SHIELD WIRE 100 2.0/3PX1 2.0/3PX1
35-MCD716-18A1 AUX PCB
R1801 BARE WIRE ĭ0.6X40mm (375m=1kG)
R1803 BARE WIRE ĭ0.6X40mm (375m=1kG)
D121 MCD716 MOTRO ASS'Y
1300 WORM PREFORMING(NEW1300)
SINGLE MOTOR WHEEL WHITE
MCD728 WORM WHEEL
MCD728 WORM
NE1300 WORM WHEEL BRACKET
MOTOR RF-360C-13450
FIBRE GASKET ĭ3X8X1
LEATHER ĭ25.5X1.3 RUBBER
SCREW 3 X 4 FM NICKEL-PLATE
SCREW 3 X 10 PA NICKEL-PLATE
28WIRE 200 2.5/2PX1
D125 ECO6-05 TUNER BOARD ASS'Y(RDS)
R18 CHIP RESISTOR 100K 1/16W J(0603)
R8 CHI P RESISTOR 10K 1/16W J(0603)
R15 CHIP RESISTOR 10K 1/16W J(0603)
R16 CHIP RESISTOR 10K 1/16W J(0603)
R19 CHIP RESISTOR 10 1/16W J(0603)
R2 CHI P RESISTOR 1M 1/16W J(0603)
R3 CHI P RESISTOR 1M 1/16W J(0603)
R12 CHIP RESISTOR 1M 1/16W J(0603)
R4 CHI P RESISTOR 4.7K 1/16W J(0603)
R5 CHI P RESISTOR 4.7K 1/16W J(0603)
R6 CHI P RESISTOR 4.7K 1/16W J(0603)
R1 CHI P RESISTOR 47 1/16W J(0603)
R11 CHIP RESISTOR 10M 1/16W J (0603)
R13 CHIP RESISTOR 820 1/16W J(0603)
R14 CHIP RESISTOR 820 1/16W J(0603)
C14 CHIP CAP.10P 50V J (0603) NPO
R22 CHIP RESISTOR 330 1/16W J(0603)
C20 CHIP CAP.12P 50V J(0603)NPO
C25 CHIP CAP.223P 50V M (0603) Y5V
C21 CHIP CAP.39P 50V J (0603) NPO
C8 CHI P CAP.47P 50V J(0603)NPO
C1 TAN TALUM CAP. 22uF/6.3V (A) (3216)
C18 TANTALUM CAP. 22uF/6.3V (A) (3216)
C19 TANTALUM CAP. 22uF/6.3V (A) (3216)
C22 TANTALUM CAP. 22uF/6.3V (A) (3216)
C24 TANTALUM CAP. 22uF/6.3V (A) (3216)
C2 CHI P CAP.224P 50V M (0603) Y5V
C3 CHI P CAP.224P 50V M (0603) Y5V
C4 CHI P CAP.224P 50V M (0603) Y5V
C5 CHI P CAP.224P 50V M (0603) Y5V
C7 CHI P CAP.27P 50V J(0603) NPO
C6 CHI P CAP.100P 50V K (0603) X7R
C23 CHIP CAP.100P 50V K (0603) X7R
C10 CHIP CAP.103P 50V K (0603) X7R
C11 CHIP CAP.103P 50V K (0603) X7R
15-2
FACTORY PARTLIST
