Philips MCD716 - Page 39

C15 CHIP CAP.103P 50V K (0603) X7R
C16 CHIP CAP.103P 50V K (0603) X7R
C17 CHIP CAP.103P 50V K (0603) X7R
C9 CHIP CAP.104P 50V M (0603) Y5V
C12 CHIP CAP.104P 50V M (0603) Y5V
C13 CHIP CAP.104P 50V M (0603) Y5V
L1 CHIP INDUCTOR 120n (0603)
L7 CHIP INDUCTOR 39n J (0603)
L8 CHIP INDUCTOR 10U (0603)
DZ1 CHIP ZENER DIODE 3.6V 1/2W (LL-34)
Q2 CHIP TRANSISTOR 9014 (SOT-23)
Q3 CHIP TRANSISTOR 9014 (SOT-23)
Q1 CHIP TRANSISTOR 8050(SOT-23)
IC2 IC 74HC2G04
IC1 IC TEA5766UK
X1 CRYSTAL OSCILLATOR 32.768KHZ ij2X6
L4 FERRITE BEAD 601 K (0603)
L5 FERRITE BEAD 601 K (0603)
CN1 PINS CONNECTOR 2.0X2X4P H8
35-ECO6-05A1 TUNER BOARD
METAL BOX F-8A 28X26X13 NICKEL-PLATE
D123 MCD708 MECHANISIM ASS'Y (SONY KHM-313AAA)
DVD MECHANISM(SONY KHM-313AAA )
DVD MECHANISM BRACKET(RT-656n)
MCD716/12 MCU PARTS ASS'Y
DIP42 CPU U252(S3C9228 XYZ-CAN CHANGE)
MCD716/12 CPU MAIN BOARD SOFTWARE(V1.0)
D126 MCD716/12 DECODER ASS'Y (SONY)
DVD DECODER EJS89LA716-12
MCD716/12 DVD SOFTWARE(V1.0A)SONY
D103 MCD716 USB LIGHT GUIDE ASS'Y
MCD716 USB DOOR SPRING
MCD716 USB LAMP BOARD(PMMA SILK-SCREEN)
MCD716 USB DOOR ABS
MCD716 USB DOOR BRACKET ABS
D106 MCD705 FUNCTION BUTTON ASS'Y
MCD705 DVD CONTROL BUTTON BRACKET ABS
MCD705 DVD CONTROL BUTTON ABS SILVER
MCD705 DVD CONTROL BUTTON ABS SILVER
D105 MCD705 PLAY BUTTON ASS'Y
MCD705 RIG OUT METAL PLATE ALUMINIUM
MCD705 DVD CONTROL BUTTON CENTRE
D107 MCD705 DSC BUTTON ASS'Y
MCD759 DVD LEAP KNOB BRACKET ABS
MCD759 DSC LEAP KNOB SILVER ABS
MCD759 OPEN/CLOSE KNOB SILVER ABS
MCD716/12DVD CASING PARTS ASS'Y
D116 MCD716 DVD BOTTOM PLATE
D114 MCD716 DVD AL.SIDE PLATE(L)
D115 MCD716 DVD AL.SIDE PLATE(R) PMS430C
D129 MCD716 DVD BACK CAB. (ABS SCART)
D135 MCD728 DVD TOP COVER(ABS HIGH BLACK)
D108 MCD705 DVD FRONT PANEL ABS
D130 MCD705 TOP COVER1 PC
D131 MCD705 TOP COVER LIGHT GUIDE(PMMA)
D117 MCD705 DVD BOTTOM CAB. (HIPS)
D122 MCD705 DVD DOOR ABS
D102 MCD705 DVD DOOR BRACKET ABS
D113 MCD705 DVD DOOR SLIDING PLANK ABS
D104 MCD705 DOOR SLIDING-BRACKET-L POM
D104 MCD705 DOOR SLIDING-BRACKET-R POM
D101 MCD705 DVD DISPLAY LENS(PMMA)
D124 MCD705 DVD MECHANISM BRACKET ABS
D120 MCD705 DOOR DRIVE MOTOR BRACKET ABS
SCREW 3 X 6 FMTT ĭ6 BLACK
SCREW 3 X 6 FMTT ĭ6 NICKEL-PLATE
15-3
FACTORY PARTLIST
