Philips MCD716 - Page 40

SCREW 2.6 X 5 PWMTT BLACK
SCREW 3 X 10 FA ĭ5.5 PLATE
SCREW 3 X 10 PWA PLATE
SCREW 3 X 8 BM NICKEL-PLATE
SCREW 2.6 X 8 PT NICKEL-PLATE
SCREW 2.6 X 6 PT NICKEL-PLATE
SCREW 2X6PWT ĭ7 BLACK
SCREW 2 X 6 PT NICKEL-PLATE
SCREW 3 X 10 PTH NICKEL-PLATE
SCREW 2.5 X 7 PWMTT BLACK
SCREW 3 X 5 FMTT NICKEL-PLATE
SCREW 3 X 6 FMTT ĭ6 BLACK
SCREW 3X6 PT NICKEL-PLATE
SCREW 3 X 6 BM NICKEL-PLATE
SCREW 3X6 FT ĭ6 BLACK
SCREW 3X8FT BLACK
SCREW 3X8 FT NICKEL-PLATE
SCREW 3 X 10 BT NICKEL-PLATE SCREW 2.5
SCUTCHEON PHILIPS 56X10 ALM
MCD705RUBBER FOOT A 70° GRAY
MCD705 B RUBBER FOOT 70°(GRAY)
BLACK SPONGE 10X10X4 75°
BLACK SPONGE 10X10X10 40°
PRICK-LINE L=70
FLAT FLEXIBLE CABLE 24PX130X0.5XA
28WIRE 100 2.0/5PX2
28 WIRE 260 2.0/6PX2
28WIRE 110 2.0/2P 2.0/3P 2.0/5P
MCD716/12 AMP UNIT PARTS ASS'Y
A118 MCD716/12 POWER BOARD ASS'Y
IC TDA8947J
POWER PCB ASS'Y POW181A 100W
MCD716 HEAT SINK 40X42X90
1204 AMP METAL BRACKET 16X9.5X7.0
A123 MCD716 TOP COVER LAMP BOARD 1 ASS'Y
R904 CHIP RESISTOR 680 1/4W J (1206)
R905 CHIP RESISTOR 680 1/4W J (1206)
LED1103 LED ĭ3 3B4SCB01 (BLUE)
LED1104 LED ĭ3 3B4SCB01 (BLUE)
35-MCD716-11A1 TOP COVER LAMP BOARD
A122 MCD728 TOP COVER 2(ABS BLACK)
28 SINGLE WIRE 150 2.0/2PX1 RED BLACK
28WIRE 190 2P
A123 MCD716 TOP COVER LAMP BOARD 2 ASS'Y
R906 CHIP RESISTOR 680 1/4W J (1206)
R907 CHIP RESISTOR 680 1/4W J (1206)
LED1100 LED ĭ3 3B4SCB01 (BLUE)
LED1101 LED ĭ3 3B4SCB01 (BLUE)
PCB 35-MCD716-11A2 TOP COVER LAMP BOARD
A124 MCD716 TOP COVER LAMP PCB ASS'Y
R903 CHIP RESISTOR 680 1/4W J (1206)
R909 CHIP RESISTOR 680 1/4W J (1206)
LED1200 LED ĭ3 3B4SCB01 (BLUE)
LED1201 LED ĭ3 3B4SCB01 (BLUE)
PCB 35-MCD716-12A1 TOP COVER LAMP BOARD
A109 MCD716 REMOTE CONTROL BOARD ASS'Y
R901 CARBON FILM RESISTOR 100 1/8W J-52
R903 CARBON FILM RESISTOR 10K 1/8W J-52
R904 CARBON FILM RESISTOR 10K 1/8W J-52
R902 CARBON FILM RESISTOR 1.5K 1/8W J-52
C902 CERAMIC CAP. 104P 50V K-5
C901 ELECTROLYTIC CAP.100u 16V L-5 5X11
15-4
FACTORY PARTLIST
