Philips MCD772 - Page 38

A006 MCD772 VOLUME BOARD ASS'Y
R203 CARBON FILM RESISTOR 10K 1/8W J-52
R204 CARBON FILM RESISTOR 10K 1/8W J-52
R201 CARBON FILM RESISTOR 4.7K 1/8W J-52
R202 CARBON FILM RESISTOR 4.7K 1/8W J-52
R205 CARBON FILM RESISTOR 680 1/8W J-52
C201 CERAMIC CAP.103P 50V K-5
C202 CERAMIC CAP.103P 50V K-5
C203 CERAMIC CAP.103P 50V K-5
C204 CERAMIC CAP.103P 50V K-5
C205 CERAMIC CAP. 104P 50V K-5
C206 CERAMIC CAP. 104P 50V K-5
C207 ELECTROLYTIC CAP.100u 16V L-5 105°C 6.3X
L201 AXIAL FIXED INDUCTOR 10u 52
D201 DIODE 4148-52
LED201 LED 2X3X4 23004BCH09-357
Q201 TRANSISTOR 8050C-5
ENCODER201 CODER(ED-1612-00-F15 40-80G)
ENCODER202 CODER R161EC-D1-15F-12CC
RV201 RESISTOR 100KB RV161NH-B100K-15F-CC-F
RV202 RESISTOR 100KB RV161NH-B100K-15F-CC-F
VOLUME PCB 35-MCD772-02A1
JP119 BARE WIRE Φ0.6X40mm (375m=1kG)
JP120 BARE WIRE Φ0.6X40mm (375m=1kG)
28WIRE CABLE 240 2.0/13PX1 2.0/11PX1
A005 MCD772 HEADPHONE BOARD ASS'Y
J401 HEADPHONE JACK Φ3.5 TE-03501S-11
HEADPHONE PCB 35-MCD772-04A1
26SHIELDINGING 320 2.0/4PX1 2.0/4PX1
A002 MCD770 VOLUME KNOB PARTS
A002A MCD770 VOLUME KNOB COVER(SILVER)
A002B MCD770 VOLUME KNOB CORE(ABS)
A001 MCD772 VOLUME FUNCTION KNOB PARTS
A001A MCD772 VOLUME FUNCTION KNOB COVER
A001B MCD772 VOLUME FUNCTION KNOB CORE
A004 MCD772 AMP PLASTIC CABINET ASS'Y
A004B MCD772 AMP PLASTIC CABINET
A004A MCD772 VOLUME KNOB LIGHT-GUIT PMMA
MCD772/93 AMP CASING PARTS ASS'Y
METAL PLATE 19X7X1 Φ3
SCUTCHEON PHILIPS 22X4.3
A003 MCD772 AMP ALUMINUM PANEL SILVER
A016 MCD770 DVD ALUMINUM TOP COVER
MCD772 AMP MATAL PLATE 109X82X3
A009 MCD770 AMP METAL BOTTOM CHASSIS
A011 MCD772 AMP BACK METAL PLATE
A008 MCD770 PLASTIC FOOT(HIPS)
A007 MCD770 RUBBER PAD Φ12X1.5 RUBBER BLACK
SCREW 2.6 X 8 PA (PLATING)
SCREW 3 X 8 BA (PLATING)
SCREW 3 X 5 FMTT (PLATING)
SCREW 3 X 5 BM (PLATING)
SCREW 3 X 5 BMTT (PLATING)
TORX STTP T-10 3.0X6.0 AB3
PHILIPS TORX T-10 1.5P 3.0X10.0 AB3
SCREW 3 X 10 PMTT (PLATING)
TORX T-10 STTB 3.0X15.0 AB3
Factory Partlist--AMP Parts
13-1
