Unsupported formats:
Empty albums: an empty album is an
album that does not contain MP3/WMA
ÀOHVDQGLVQRWEHVKRZQLQWKHGLVSOD\
8QVXSSRUWHGÀOHIRUPDWVDUHVNLSSHG)RU
example, Word documents (.doc) or MP3
ÀOHVZLWKH[WHQVLRQGOIDUHLJQRUHGDQG
not played.
$$&:$93&0DXGLRÀOHV
'50SURWHFWHG:0$ÀOHVZDYPD
.m4p, .mp4, .aac)
:0$ÀOHVLQ/RVVOHVVIRUPDW
Supported MP3 disc formats
ISO9660, Joliet
Maximum title number: 999 (depending
RQÀOHQDPHOHQJWK
Maximum album number: 99
Supported sampling frequencies: 32 kHz,
44.1kHz, 48 kHz
Supported Bit-rates: 32-320 (kbps),
variable bit rates
ID3 tag v2.0 or later
Directory nesting up to a maximum of 8
levels
Maintenance
Clean the cabinet
Use a soft cloth slightly moistened with
a mild detergent solution. Do not use
a solution containing alcohol, spirits,
ammonia or abrasives.
Clean discs
When a disc becomes dirty,
clean it with a cleaning
cloth. Wipe the disc from
the centre out.
Do not use solvents
such as benzene, thinner,
commercially available
cleaners, or antistatic spray intended for
analogue records.
Speakers
Speaker Impedance 4ohm
Woofer 1 x 5.25”
Tweeter Ribbon tweeter
Dimensions
(W x H x D)
175 x 252 x 196mm
Weight 2.97kg each
General information
AC power 220 - 240V, 50Hz
Operation power
consumption
55W
Standby power
consumption
<15W
Eco power standby
consumption
<1W
USB direct Version 2.0/1.1
Dimensions
Main Unit (W x H x D) 179 x 252 x 340mm
Weight
(without speakers)
3.42kg
USB playability information
Compatible USB devices:
86%ÁDVKPHPRU\86%RU86%
86%ÁDVKSOD\HUV86%RU86%
memory cards (requires an additional
card reader to work with this unit)
Supported formats:
86%RUPHPRU\ÀOHIRUPDW)$7
FAT16, FAT32 (sector size: 512 bytes)
MP3 bit rate (data rate): 32-320 Kbps and
variable bit rate
WMA v9 or earlier
Directory nesting up to a maximum of 8
levels
Number of albums/ folders: maximum 99
Number of tracks/titles: maximum 999
ID3 tag v2.0 or later
File name in Unicode UTF8 (maximum
length: 128 bytes)
