Philips MRV640 - Analog Board

Spare Parts List
EN 144 DVDR615, MRV64010.
MECHANICAL PARTS
Miscellaneous
0101 3139 247 51831 BADGE PHILIPS ASSY
SILVER
0102 3139 244 04571 CAB FRONT DVDR615
0102 3139 254 00971 CAB FRONT MRV640
0110 3139 244 04561 BUTTON STANDBY
DVDR615
0110 3139 254 00961 BUTTON STANDBY
MRV640
0114 3139 244 04531 BUTTON EJECT DVDR615
0114 3139 254 00951 BUTTON EJECT MRV640
0118 3139 244 04521 BUTTON SET DVDR615
0118 3139 254 00941 BUTTON CONTROL
MRV640
0122 3139 244 04491 BUTTON CAP REC
DVDR615
0126 3139 244 04511 RING REC DVDR615
0134 3139 244 04551 COVER TRAY DVDR615
0134 3139 254 00931 ORN COVER TRAY
MRV640
0138 3103 604 00811 HOLDER COVER TRAY
0138 3139 254 00921 COVER TRAY MRV640
0148 3103 603 20122 FOAM RUBBER SEALING
0150 3139 244 04541 WINDOW DVDR615
0150 3139 254 00911 WINDOW DISPLAY
MRV640
0158 3139 244 04481 WINDOW LEFT DVDR615
0160 3139 244 04471 DOOR FLAP DVDR615
0162 3103 604 00441 HINGE DOOR FRONT AV
0196 3139 111 30771 COVER TOP MRV640
0274 3103 604 00622 FOOT
0276 3103 603 20041 CUSHION FOOT
0292 3103 308 52950 FAN KD120 6PTS 3 - C112
0333 3128 147 14551 REM CONTROL RC25115/
05 (for DVDR615)
0333 3128 147 15141 REM CONTROL RC25116/
01 (for MRV640)
0336
 2422 070 98134 MAINSCORD USA 1M8 BK
B
0340 3103 308 92610 CABLE AUDIO 2X2RCA
MALE 1.5MTR
0341 4822 321 61579 VIDEO-CABLE
0344 4822 320 11096 ANTENNA CABLE NTSC
0384 9082 100 01504 DVD-RW DISK DVDRW/620
B
8102 3103 601 00200 FFC 7-POL-A-TYP 240MM
(DB-AB)
8104 3103 601 00220 FFC 10-POL-D-TYP 350MM
(UP-DB)
8105 3103 601 00230 FFC 22-POL-A-TYP 210MM
(AB-DB)
8109 3103 601 00471 CBLE EHR 4P/180/4P LC UL
8110 3103 601 00280 FFC 10-POL-A-TYP 650MM
(AB-DC)
8112 3104 311 05501 CBLE IDE 40P/480/40P IDE
8119 3103 601 00360 IEEE 1394 CHRYSALIS
350MM
8126 3103 601 00431 FFC 22-POL-A-TYP 245MM
(AB-DB)
Analog Board
Various
1001 2422 086 10769 FUSE RAD LT 125MA 250V
IEC A
1300
 4822 253 30383 FUSE 5X20 HT 2A5 250V
IEC B
1301
 4822 265 11253 FUSE HOLDER 2P
1302
 4822 252 11215 DSP301N-A21F
1303
 4822 071 51002 FUSE RAD LT 1A 250V IEC
A
1304
 9965 000 07786 FUSE RAD T4.0A IEC
UL250V
1306
 2422 086 10769 FUSE RAD LT 125MA 250V
IEC A
1307
 4822 071 51002 FUSE RAD LT 1A 250V IEC
A
1308
 9965 000 07787 FUSE RAD T500MA IEC
UL250V
1309
 9965 000 07788 FUSE RAD T2A IEC UL250V
1600 4822 242 10434 L1101-95263-
0E1(18,432MHZ)
1701 2422 542 90139 TUMOD V+U PLL F MN B
1900 4822 265 11154 52030-2210 (22P)
1931
 2422 030 00304 SOC SUPP AC HOR MALE
9452 B
1941 2422 026 05291 SOC CINCH H 8P F
YEWHRDBU
1943 4822 267 11031 10P. FEM. V
1944 2422 026 05291 SOC CINCH H 8P F
YEWHRDBU
1946 2422 025 17367 CON BM V7P F1.00FFC
0.03B
1947 4822 265 11154 52030-2210 (22P)
1948 4822 267 10994 4P, MDIN
1949 4822 267 10994 4P, MDIN
1951 4822 267 31729 SOC CINCH H 1P F BK B

2001 4822 124 80483 47uF 20% 6,3V
2002 2238 586 59812 100nF +80/-20% 50V
2003 2238 586 59812 100nF +80/-20% 50V
2006 4822 126 11785 47pF 5% 50V
2007 4822 124 21732 10uF 20% 25V
2008 3198 016 31020 1nF 25V
2009 2238 586 59812 100nF +80/-20% 50V
2010 4822 124 80483 47uF 20% 6,3V
2011 4822 124 21732 10uF 20% 25V
2012 2238 586 59812 100nF +80/-20% 50V
2013 4822 124 42234 100uF 20% 6,3V
2014 2238 586 59812 100nF +80/-20% 50V
2015 2238 586 59812 100nF +80/-20% 50V
2018 2238 586 59812 100nF +80/-20% 50V
2019 2238 586 59812 100nF +80/-20% 50V
2020 4822 124 80483 47uF 20% 6,3V
2023 4822 124 12392 47uF 20% 16V
2024 4822 126 11669 27pF
2025 3198 016 31020 1nF 25V
2026 4822 126 11669 27pF
2029 4822 124 12392 47uF 20% 16V
2033 4822 126 13881 470pF 5% 50V
2034 4822 126 13881 470pF 5% 50V
2037 4822 126 13193 4,7nF 10% 63V
2038 4822 126 13193 4,7nF 10% 63V
2039 4822 126 13193 4,7nF 10% 63V
2040 4822 126 13193 4,7nF 10% 63V
2301
 2020 554 90173 2,2nF 20% 250V
2302
 4822 121 10512 220nF 20% 275V
2303 4822 122 31175 1nF 10% 500V
2304
 4822 121 51598 2,2nF 5% 400V
2305 2020 021 91506 1000uF 20% 16V
2306 2020 021 91528 560uF 20% 6V3
2307 4822 122 31175 1nF 10% 500V
2308 2022 318 00108 47nF 10% 250V
2309
 2222 152 90004 330uF 20% 200V
2310 5322 126 11578 1nF 10% 50V
2311 5322 126 11578 1nF 10% 50V
2312 2020 021 91506 1000uF 20% 16V
2313 2020 021 91528 560uF 20% 6V3
2315
 4822 126 12263 220pF 10% 2KV
2317 5322 126 11578 1nF 10% 50V
2318 4822 124 21732 10uF 20% 25V
2319 2020 021 91506 1000uF 20% 16V
2320 4822 124 40849 330uF 20% 16V
2321 2238 586 59812 100nF +80/-20% 50V
2322
 2020 021 91506 1000uF 20% 16V
2323 4822 124 42234 100uF 20% 6,3V
2324 2238 586 59812 100nF +80/-20% 50V
2325 4822 124 81151 22uF 50V
2326 4822 121 41857 10nF 5% 250V
2327 2238 586 59812 100nF +80/-20% 50V
2328 4822 124 81151 22uF 50V
2329 2238 586 59812 100nF +80/-20% 50V
2330 5322 126 11578 1nF 10% 50V
2331 2238 586 59812 100nF +80/-20% 50V
2332 4822 124 22651 1,0uF 20% 50V
2334 2238 586 59812 100nF +80/-20% 50V
2335 4822 126 10206 2,2nF 10% 500V
2336 2238 586 59812 100nF +80/-20% 50V
2338 2238 586 59812 100nF +80/-20% 50V
2339 3198 017 41050 1uF 10V
2340 3198 017 41050 1uF 10V
2341 3198 017 41050 1uF 10V
2343 2238 586 59812 100nF +80/-20% 50V
2402 2238 586 59812 100nF +80/-20% 50V
2403 2238 586 59812 100nF +80/-20% 50V
2404 4822 124 80483 47uF 20% 6,3V
2405 4822 124 80483 47uF 20% 6,3V
2406 5322 126 11583 10nF 10% 50V
2409 2238 586 59812 100nF +80/-20% 50V
2410 3198 017 41050 1uF 10V
2411 2238 586 59812 100nF +80/-20% 50V
2413 2238 586 59812 100nF +80/-20% 50V
2414 4822 124 80483 47uF 20% 6,3V
2415 3198 017 41050 1uF 10V
2416 3198 017 41050 1uF 10V
2417 4822 124 11947 10uF 20% 16V
2418 3198 017 41050 1uF 10V
2419 3198 017 41050 1uF 10V
2420 2238 586 59812 100nF +80/-20% 50V
2421 4822 124 11947 10uF 20% 16V
2422 5322 126 11583 10nF 10% 50V
2424 4822 126 13881 470pF 5% 50V
2425 4822 126 13881 470pF 5% 50V
2426 2238 586 59812 100nF +80/-20% 50V
2427 2238 586 59812 100nF +80/-20% 50V
2428 4822 124 11947 10uF 20% 16V
2433 3198 017 34730 47nF 16V
2434 4822 124 80483 47uF 20% 6,3V
2435 2238 586 59812 100nF +80/-20% 50V
2437 3198 017 41050 1uF 10V
2438 3198 017 41050 1uF 10V
2439 2238 586 59812 100nF +80/-20% 50V
2441 3198 017 41050 1uF 10V
2442 3198 017 41050 1uF 10V
2446 3198 017 41050 1uF 10V
2459 3198 017 41050 1uF 10V
2464 4822 124 21732 10uF 20% 25V
2465 3198 017 41050 1uF 10V
2466 3198 017 41050 1uF 10V
2467 2238 586 59812 100nF +80/-20% 50V
2469 2238 586 59812 100nF +80/-20% 50V
2470 4822 124 21732 10uF 20% 25V
2471 2238 586 59812 100nF +80/-20% 50V
2501 3198 017 41050 1uF 10V
2502 2238 586 59812 100nF +80/-20% 50V
2503 4822 126 13881 470pF 5% 50V
2504 3198 017 41050 1uF 10V
2505 3198 017 41050 1uF 10V
2506 3198 017 41050 1uF 10V
2507 3198 017 41050 1uF 10V
2508 3198 017 41050 1uF 10V
2509 4822 126 13881 470pF 5% 50V
2510 4822 124 11947 10uF 20% 16V
2511 4822 124 11947 10uF 20% 16V
2512 2238 586 59812 100nF +80/-20% 50V
2513 4822 126 13881 470pF 5% 50V
2514 4822 126 13881 470pF 5% 50V
2515 4822 124 80483 47uF 20% 6,3V
2516 2238 586 59812 100nF +80/-20% 50V
2517 2238 586 59812 100nF +80/-20% 50V
2518 4822 124 80483 47uF 20% 6,3V
2521 4822 126 13881 470pF 5% 50V
2522 4822 126 13881 470pF 5% 50V
2524 3198 017 41050 1uF 10V
2525 3198 017 41050 1uF 10V
2580 2238 586 59812 100nF +80/-20% 50V
2581 4822 124 42234 100uF 20% 6,3V
2582 2238 586 59812 100nF +80/-20% 50V
2583 2238 586 59812 100nF +80/-20% 50V
2585 2238 586 59812 100nF +80/-20% 50V
2586 5322 126 11578 1nF 10% 50V
2587 3198 017 41050 1uF 10V
2590 4822 122 33753 150pF 5% 50V
2600 4822 124 21732 10uF 20% 25V
2601 5322 126 11583 10nF 10% 50V
2602 4822 124 21732 10uF 20% 25V
2603 2238 586 59812 100nF +80/-20% 50V
2604 5322 126 11583 10nF 10% 50V
2605 4822 124 21732 10uF 20% 25V
2606 2238 586 59812 100nF +80/-20% 50V
2607 4822 126 14225 56pF 5% 50V 0603
2608 4822 124 21732 10uF 20% 25V
2609 4822 126 14225 56pF 5% 50V 0603
2610 5322 126 11583 10nF 10% 50V
2611 4822 124 80231 47uF 20% 16V
2612 4822 124 40769 4,7uF 20% 100V
2616 5322 126 11578 1nF 10% 50V
2617 5322 126 11578 1nF 10% 50V
2620 3198 016 33380 3,3pF 50V
2621 3198 016 33380 3,3pF 50V
2623 2238 586 59812 100nF +80/-20% 50V
2624 4822 124 22652 2,2uF 20% 50V
2625 4822 124 22652 2,2uF 20% 50V
2631 5322 126 11578 1nF 10% 50V
2700 4822 126 14549 33nF 16V
2701 4822 124 40769 4,7uF 20% 100V
2702 5322 126 11583 10nF 10% 50V
2703 4822 124 40769 4,7uF 20% 100V
2704 5322 126 11583 10nF 10% 50V
2707 4822 124 80483 47uF 20% 6,3V

3001 4822 117 13613 2R2 5% 0,062W
3002 4822 117 13613 2R2 5% 0,062W
3003 4822 051 30103 10k 5% 0,062W
3004 4822 117 12139 22R 5% 0,062W
3005 4822 117 12139 22R 5% 0,062W
3006 4822 117 12139 22R 5% 0,062W
3007 4822 117 12925 47k 1% 0,063W
