Philips MRV640 - Page 147

Spare Parts List
EN 147DVDR615, MRV640 10.
7803 9322 202 01668 M68AW127BM-70MC6
AN7300XX
7804 3103 165 13721 IC TMP91CW12AF/LIRP1
7805 9965 000 16965 M29W800DT-70N6/
AN430045
7806 9322 163 26685 NCP301LSN30
7807 4822 209 73852 PMBT2369
7808 4822 209 16907 M24C16-MN6T
7813 3198 010 42310 BC847BW
7814 3198 010 42310 BC847BW
7815 3198 010 42310 BC847BW
7816 3198 010 42310 BC847BW
7817 3198 010 42310 BC847BW
7818 4822 130 60854 DTA124EU-W
7821 9340 560 36235 BSH111
7822 9340 560 36235 BSH111
7825 9322 181 92682 LA7213
7902 4822 209 63709 LM324D
7903 4822 130 61553 DTC124EU
7904 4822 130 60854 DTA124EU-W
7905 4822 130 61553 DTC124EU
7906 4822 130 61553 DTC124EU
7907 4822 130 61553 DTC124EU
7908 4822 130 61553 DTC124EU
7909 4822 130 41087 BC638
7910 4822 130 61553 DTC124EU
Digital Board Chrysalis 2.1
Various
1001 2422 543 01422 RES XTL SM 24M576 18P
CX8045 R
1001 2422 543 89017 RES XTL SM 24M576 18P
CX-11F R
1102 2422 025 18185 CON V 40P M 2.54 SM
440090 R
1103 2422 025 17104 CON BM V 7P M 2.00 PH
SMD R
1104 2422 025 16729 CON BM V 10P F 1.00 FFC
0.3 R
1201 2422 543 01115 RES XTL SM 24M576 12P
CX-11F R
1201 2422 543 01368 RES XTL SM 24M576 12P
CX8045 R
1203 2422 025 17955 CON V 6P M 1.00 SM SR R
1500 2422 025 17441 CON BM V 12P M 2.00 PH
SMD R
1505
 2422 086 11087 FUSE SM F 1A 125V UL R
1506
 2422 086 11087 FUSE SM F 1A 125V UL R
1507
 2422 086 11087 FUSE SM F 1A 125V UL R
1704 2422 025 16794 CON BM V 7P F 1.00 FFC
0.3 R
1900 2422 025 16389 CON BM V 22P F 1.00 FFC
0.3 R
1901 2422 025 16987 CON V 6P F 1.00 SM FFC
0.3 R
1904 2422 025 16389 CON BM V 22P F 1.00 FFC
0.3 R

2014 4822 124 80151 47uF 16V
2015 2238 586 59812 100nF +80/-20% 50V
2016 2238 586 59812 100nF +80/-20% 50V
2017 2238 586 59812 100nF +80/-20% 50V
2018 2238 586 59812 100nF +80/-20% 50V
2019 2238 586 59812 100nF +80/-20% 50V
2020 2238 586 59812 100nF +80/-20% 50V
2021 2238 586 59812 100nF +80/-20% 50V
2022 2020 021 91729 4,7uF 20% 35V
2026 2238 586 59812 100nF +80/-20% 50V
2027 2238 586 59812 100nF +80/-20% 50V
2028 2238 586 59812 100nF +80/-20% 50V
2029 2238 586 59812 100nF +80/-20% 50V
2030 2238 586 59812 100nF +80/-20% 50V
2031 2238 586 59812 100nF +80/-20% 50V
2032 2238 586 59812 100nF +80/-20% 50V
2033 2020 021 91729 4,7uF 20% 35V
2035 2238 586 59812 100nF +80/-20% 50V
2036 4822 126 14506 270pF 5% 50V 0603
2037 2238 586 59812 100nF +80/-20% 50V
2038 2238 586 59812 100nF +80/-20% 50V
2039 2238 586 59812 100nF +80/-20% 50V
2040 2238 586 59812 100nF +80/-20% 50V
2041 2238 586 59812 100nF +80/-20% 50V
2042 2238 586 59812 100nF +80/-20% 50V
2043 2238 586 59812 100nF +80/-20% 50V
2044 2020 021 91729 4,7uF 20% 35V
2046 4822 122 33761 22pF 5% 50V
2048 4822 122 33753 150pF 5% 50V
2049 2020 021 91729 4,7uF 20% 35V
2050 2238 586 59812 100nF +80/-20% 50V
2052 2238 586 59812 100nF +80/-20% 50V
2053 2238 586 59812 100nF +80/-20% 50V
2054 2238 586 59812 100nF +80/-20% 50V
2056 2238 586 59812 100nF +80/-20% 50V
2058 2238 586 59812 100nF +80/-20% 50V
2059 2222 867 15339 33pF 5% 50V
2060 2222 867 15339 33pF 5% 50V
2061 2238 586 59812 100nF +80/-20% 50V
2063 2238 586 59812 100nF +80/-20% 50V
2064 2238 586 59812 100nF +80/-20% 50V
2065 2238 586 59812 100nF +80/-20% 50V
2066 3198 016 31020 1nF 25V
2067 2238 586 59812 100nF +80/-20% 50V
2071 2238 586 59812 100nF +80/-20% 50V
2101 2238 916 15641 22nF 10% 25V
2103 2238 586 59812 100nF +80/-20% 50V
2108 4822 126 14585 100nF 10% 0805 50V
2112 4822 126 14247 1,5nF 50V
2113 4822 126 13881 470pF 5% 50V
2116 2238 586 59812 100nF +80/-20% 50V
2119 4822 126 14247 1,5nF 50V
2120 2238 586 59812 100nF +80/-20% 50V
2125 2238 586 59812 100nF +80/-20% 50V
2200 3198 017 41050 1uF 10V
2201 4822 126 14506 270pF 5% 50V 0603
2202 4822 126 11663 12pF
2203 4822 126 11663 12pF
2206 2238 586 59812 100nF +80/-20% 50V
2207 2238 586 59812 100nF +80/-20% 50V
2209 2238 586 59812 100nF +80/-20% 50V
2210 2238 586 59812 100nF +80/-20% 50V
2212 4822 124 12095 100uF 20% 16V
2214 2238 586 59812 100nF +80/-20% 50V
2215 2238 586 59812 100nF +80/-20% 50V
2217 2238 586 59812 100nF +80/-20% 50V
2218 2238 586 59812 100nF +80/-20% 50V
2219 2238 586 59812 100nF +80/-20% 50V
2220 2238 586 59812 100nF +80/-20% 50V
2221 2238 586 59812 100nF +80/-20% 50V
2222 2238 586 59812 100nF +80/-20% 50V
2223 2238 586 59812 100nF +80/-20% 50V
2224 2238 586 59812 100nF +80/-20% 50V
2225 2238 586 59812 100nF +80/-20% 50V
2226 2238 586 59812 100nF +80/-20% 50V
2227 2238 586 59812 100nF +80/-20% 50V
2228 2238 586 59812 100nF +80/-20% 50V
2229 2238 586 59812 100nF +80/-20% 50V
2230 2238 586 59812 100nF +80/-20% 50V
2231 2238 586 59812 100nF +80/-20% 50V
2232 2238 586 59812 100nF +80/-20% 50V
2233 2238 586 59812 100nF +80/-20% 50V
2234 2238 586 59812 100nF +80/-20% 50V
2235 3198 016 31020 1nF 25V
2236 2020 021 91729 4,7uF 20% 35V
2237 2238 586 59812 100nF +80/-20% 50V
2238 2238 586 59812 100nF +80/-20% 50V
2308 2238 586 59812 100nF +80/-20% 50V
2310 2238 586 59812 100nF +80/-20% 50V
2403 2238 586 59812 100nF +80/-20% 50V
2404 4822 124 23002 10uF 16V
2405 2238 586 59812 100nF +80/-20% 50V
2406 2238 586 59812 100nF +80/-20% 50V
2407 2238 586 59812 100nF +80/-20% 50V
2408 4822 124 23002 10uF 16V
2409 2238 586 59812 100nF +80/-20% 50V
2410 2238 586 59812 100nF +80/-20% 50V
2411 2238 586 59812 100nF +80/-20% 50V
2412 2238 586 59812 100nF +80/-20% 50V
2413 2238 586 59812 100nF +80/-20% 50V
2414 2238 586 59812 100nF +80/-20% 50V
2415 2238 586 59812 100nF +80/-20% 50V
2416 2238 586 59812 100nF +80/-20% 50V
2417 2238 586 59812 100nF +80/-20% 50V
2418 4822 124 23002 10uF 16V
2419 2238 586 59812 100nF +80/-20% 50V
2420 4822 124 23002 10uF 16V
2421 2238 586 59812 100nF +80/-20% 50V
2422 2238 586 59812 100nF +80/-20% 50V
2423 2238 586 59812 100nF +80/-20% 50V
2424 2238 586 59812 100nF +80/-20% 50V
2425 2238 586 59812 100nF +80/-20% 50V
2426 2238 586 59812 100nF +80/-20% 50V
2427 2238 586 59812 100nF +80/-20% 50V
2428 2238 586 59812 100nF +80/-20% 50V
2429 2238 586 59812 100nF +80/-20% 50V
2430 4822 051 30152 1k2 5% 0,062W
2432 2238 586 59812 100nF +80/-20% 50V
2433 2238 586 59812 100nF +80/-20% 50V
2512 2020 021 91672 100uF 20% 6V3
2512 2020 021 91857 100uF 20% 6V3
2514 2238 586 59812 100nF +80/-20% 50V
2515 3198 017 44740 470nF 10V
2516 2020 021 91672 100uF 20% 6V3
2516 2020 021 91857 100uF 20% 6V3
2518 2020 552 94427 100pF 5% 50V
2519 2238 586 59812 100nF +80/-20% 50V
2521 2238 586 59812 100nF +80/-20% 50V
2524 2238 586 59812 100nF +80/-20% 50V
2525 2238 586 59812 100nF +80/-20% 50V
2526 2238 586 59812 100nF +80/-20% 50V
2527 5322 126 11583 10nF 10% 50V
2700 2020 021 91729 4,7uF 20% 35V
2701 2238 586 59812 100nF +80/-20% 50V
2703 3198 016 31020 1nF 25V
2704 2238 586 59812 100nF +80/-20% 50V
2705 2238 586 59812 100nF +80/-20% 50V
2706 2238 586 59812 100nF +80/-20% 50V
2707 2238 586 59812 100nF +80/-20% 50V
2708 4822 126 14487 8,2pF 0,5% 50V
2709 4822 122 33761 22pF 5% 50V
2710 4822 126 14507 18pF 5% 50V
2712 2238 586 59812 100nF +80/-20% 50V
2714 4822 126 14487 8,2pF 0,5% 50V
2715 4822 122 33761 22pF 5% 50V
2716 4822 126 14507 18pF 5% 50V
2719 4822 126 14487 8,2pF 0,5% 50V
2720 4822 122 33761 22pF 5% 50V
2721 4822 126 14507 18pF 5% 50V
2723 2238 586 59812 100nF +80/-20% 50V
2724 4822 124 80151 47uF 16V
2725 2238 586 59812 100nF +80/-20% 50V
2726 2238 586 59812 100nF +80/-20% 50V
2727 2238 586 59812 100nF +80/-20% 50V
2728 2020 021 91729 4,7uF 20% 35V
2729 2020 021 91729 4,7uF 20% 35V
2806 2238 586 59812 100nF +80/-20% 50V
2807 2238 586 59812 100nF +80/-20% 50V
2808 2238 586 59812 100nF +80/-20% 50V
2809 2238 586 59812 100nF +80/-20% 50V
2810 2238 586 59812 100nF +80/-20% 50V
2811 2238 586 59812 100nF +80/-20% 50V
2812 2238 586 59812 100nF +80/-20% 50V
2820 2238 586 59812 100nF +80/-20% 50V
2821 2238 586 59812 100nF +80/-20% 50V
2822 2238 586 59812 100nF +80/-20% 50V
2823 2238 586 59812 100nF +80/-20% 50V
2824 2238 586 59812 100nF +80/-20% 50V
2825 2238 586 59812 100nF +80/-20% 50V
2826 2238 586 59812 100nF +80/-20% 50V
2830 2238 586 59812 100nF +80/-20% 50V
2832 2238 586 59812 100nF +80/-20% 50V
2833 2238 586 59812 100nF +80/-20% 50V
2900 2238 586 59812 100nF +80/-20% 50V
2901 2238 586 59812 100nF +80/-20% 50V
2902 2238 586 59812 100nF +80/-20% 50V
2903 2238 586 59812 100nF +80/-20% 50V
2904 2238 586 59812 100nF +80/-20% 50V
2905 2238 586 59812 100nF +80/-20% 50V
2906 2238 586 59812 100nF +80/-20% 50V
2907 2238 586 59812 100nF +80/-20% 50V
2908 2238 586 59812 100nF +80/-20% 50V
2909 2238 586 59812 100nF +80/-20% 50V
2910 4822 122 33761 22pF 5% 50V
2911 2238 916 15641 22nF 10% 25V
2912 2238 586 59812 100nF +80/-20% 50V
2913 2238 586 59812 100nF +80/-20% 50V
2914 4822 126 14506 270pF 5% 50V 0603
2915 4822 126 14506 270pF 5% 50V 0603
2916 4822 126 14506 270pF 5% 50V 0603
2917 4822 126 14506 270pF 5% 50V 0603
2918 4822 122 33761 22pF 5% 50V
2919 4822 122 33761 22pF 5% 50V
2920 2238 586 59812 100nF +80/-20% 50V
2921 4822 122 33761 22pF 5% 50V
2922 4822 122 33761 22pF 5% 50V
2923 2238 586 59812 100nF +80/-20% 50V
2924 2238 586 59812 100nF +80/-20% 50V
2926 4822 126 14506 270pF 5% 50V 0603
2927 4822 126 14506 270pF 5% 50V 0603
2928 4822 126 14506 270pF 5% 50V 0603
2929 4822 126 14506 270pF 5% 50V 0603
2930 2238 586 59812 100nF +80/-20% 50V
2931 2020 021 91729 4,7uF 20% 35V
2933 2238 586 59812 100nF +80/-20% 50V
2934 2238 586 59812 100nF +80/-20% 50V
2935 4822 126 14506 270pF 5% 50V 0603
2936 4822 126 14506 270pF 5% 50V 0603
2937 4822 126 14506 270pF 5% 50V 0603
2938 2238 586 59812 100nF +80/-20% 50V
2939 2020 021 91729 4,7uF 20% 35V
2940 2238 586 59812 100nF +80/-20% 50V

3000 4822 051 30681 680Ω 5% 0.062W
