Diagnostic Software
EN 28 DVDR615, MRV6405.
Digital Video Input Output (DVIO)
User Input The input to select, see table below.
1 CVBS_Y_IN_A
2 CVBS_OUT_B
3 CVBS_Y_IN_B
4 CVBS_Y_IN_C
6 C_IN
8 G_IN
9 Y_IN
13 B_IN
14 U_IN
18 R_IN
19 V_IN
Error Number Description
60400 Selecting the input of the VIP succeeded
60401 The user provided wrong input
60402 The VIP was not accessible
Example DS:> 604 1
060400:
Test OK @
Nucleus Name DS_DVIO_LinkDevTypeGet
Nucleus Number 700
Description Get the device (revision) type information of the 1394 Link layer IC
Technical - Initialise the PIO pins on the chrysalis
- Read out the ID register
Execution Time Less than 1 second
User Input None
Error Number Description
70000 Getting the information from the link layer IC succeeded
70001 Getting the information from the link layer IC failed
70002 Type not according to type stored in HW diversity string
Example DS:> 701
070100: Physical layer IC: VendorID: 0x006037, ProductID: 0x412801
Test OK @
Nucleus Name DS_DVIO_PhyDevTypeGet
Nucleus Number 701
Description Get the device (revision) type information of the 1394 Physical layer IC
User Input None
Example DS:> 700
070000: Device type of the link layer IC: ffc00301
Test OK @
Nucleus Name DS_DVIO_LinkCommunication
Nucleus Number 702
Description Check the accessibility of the 1394 Link layer IC by writing to and reading from a specific
address
Technical - Initialise the PIO pins of the chrysalis
- Write a pattern to the CYCTM register of the link chip
- Read back and verify the pattern
Execution Time Less than 1 second
User Input None
Error Number Description
70200 Communicating with the link layer IC succeeded
70201 Communicating with the link layer IC failed
70202 Result of nucleus not according to HW diversity string
Example DS:> 702
070200:
Test OK @
Nucleus Name DS_DVIO_PhyCommunication
Nucleus Number 703
Description Check the accessibility of the 1394 Physical layer IC by writing to and reading from a spe-
cific address
