Diagnostic Software
EN 32 DVDR615, MRV6405.
Basic Engine (BE)
80600 Routing path is created successfully.
80601 Unable to initialise the Chrysalis.
80602 Unable to access DENC
80603 Unable to access deinterlacer.
80604 Wrong chips were expected.
Example DS:> 806
080600:
Test OK @
Nucleus Name DS_PSCAN_DevTypeGetDeinterlacer
Nucleus Number 807
Description Get the device (revision) type information of the progressive scan deinterlacer.
Technical - Initialise the deinterlacer.
- Read the version register of the deinterlacer.
Execution Time 1 second
User Input None
Error Number Description
80700 Everything went well.
80701 The communication with the device failed
80702 No chip was expected
Example DS:> 807
080700:
Chip name : 2300
Chip version : 1
Test OK @
Nucleus Name DS_PSCAN_CommunicationDeinterlacer
Nucleus Number 808
Description Check the communication between the IIC controller of the chrysalis and the progressive
scan Deinterlacer-IC
Technical - Initialise IIC
- Set the video source synchronisation source to the Chrysalis
- Write data to the DENC through IIC
Execution Time Less than 1 second
User Input None
Error Number Description
80800 Communicating with the progressive scan Deinterlacer-IC
succeeded
80801 The IIC bus was not accessible
80802 There was a timeout reading the device
80803 The communication with the device failed (no ACK)
80804 Communicating with the progressive scan Deinterlacer-IC
failed
80805 The initialisation of the IIC bus failed
80806 The data read back is not the same as the data written
80807 No chip was expected
Example DS:> 808
080800:
Test OK @
Nucleus Name DS_BE_CommunicationEcho
Nucleus Number 900
Description Check the communication between the digital board and the basic engine by issuing an
echo command over the S2B interface
Technical - Send the ECHO command
- Check if the BE returned the string 0x00 0xAA 0x55
Execution Time Less than 1 second
User Input None
Error Number Description
90000 Communicating with the BE over the S2B interface succeed-
ed
90001 There was a time-out while communicating
90002 The Basic Engine returned an unexpected result
