ELECTRICAL PARTS LIST - MAIN BOARD ELECTRICAL PARTS LIST - MAIN BOARD

MISCELLANEOUS

JK401 9965 000 12506 SOCKET OPTICAL OUT

JK402 9965 000 12507 CINCH SOCKET 1P BLACK

JK403 9965 000 12507 CINCH SOCKET SUB-WOOFER OUT

JK405 9965 000 12505 CINCH SOCKET 6P WHITE/RED

JK500 9965 000 12502 LOUDSPEAKER SOCKET 10P

JK581 9965 000 14155 HEADPHONE SOCKET

CN102 9965 000 14144 FLEX SOCKET 16PIN VERT.

CN103 9965 000 14145 FLEX SOCKET 26PIN VERT.

XL100 9965 000 12473 CRYSTAL 27MHZ

XL500 9965 000 14167 X’TAL 6,144MHZ HC-49/U

CAPACITORS

C1 4822 124 40248 10uF 20% 63V

C2 4822 126 13221 100pF 2% NP0 63V

C3 4822 126 13221 100pF 2% NP0 63V

C4 4822 126 13221 100pF 2% NP0 63V

C5 4822 126 13221 100pF 2% NP0 63V

C6 4822 126 14585 100nF 10% X7R 0805 50V

C7 4822 126 14585 100nF 10% X7R 0805 50V

C8 9965 000 12588 1000pF 50V 5%

C9 4822 126 14585 100nF 10% X7R 0805 50V

C10 4822 126 14585 100nF 10% X7R 0805 50V

C11 9965 000 12588 1000pF 50V 5%

C12 4822 126 14585 100nF 10% X7R 0805 50V

C13 9965 000 12588 1000pF 50V 5%

C14 4822 126 14585 100nF 10% X7R 0805 50V

C15 4822 126 14585 100nF 10% X7R 0805 50V

C16 4822 126 13221 100pF 2% NP0 63V

C17 4822 126 13221 100pF 2% NP0 63V

C18 4822 126 13221 100pF 2% NP0 63V

C19 4822 126 14585 100nF 10% X7R 0805 50V

C20 4822 126 14585 100nF 10% X7R 0805 50V

C21 4822 126 14585 100nF 10% X7R 0805 50V

C22 4822 126 14585 100nF 10% X7R 0805 50V

C30 9965 000 13078 330pF 50V 5%

C38 4822 126 14585 100nF 10% X7R 0805 50V

C39 9965 000 14130 100UF 16V 20%

C40 5322 122 32331 1nF 10% 100V

C41 4822 126 13221 100pF 2% NP0 63V

C42 4822 126 13221 100pF 2% NP0 63V

C43 4822 126 13221 100pF 2% NP0 63V

C102 4822 126 14585 100nF 10% X7R 0805 50V

C103 4822 126 14585 100nF 10% X7R 0805 50V

C104 9965 000 14450 0,47uF 25V 20%

C124 2238 861 18339 33pF 1% 50V

C127 4822 126 14585 100nF 10% X7R 0805 50V

C128 9965 000 12475 470pF 50V 5%

C129 9965 000 12475 470pF 50V 5%

C130 9965 000 12475 470pF 50V 5%

C131 9965 000 12475 470pF 50V 5%

C132 9965 000 12475 470pF 50V 5%

C133 9965 000 12475 470pF 50V 5%

C134 9965 000 12475 470pF 50V 5%

C135 9965 000 12475 470pF 50V 5%

C136 4822 126 13221 100pF 2% NP0 63V

C137 4822 126 13221 100pF 2% NP0 63V

C138 4822 126 14585 100nF 10% X7R 0805 50V

C141 5322 122 32658 22pF 5% 50V

C142 5322 122 32658 22pF 5% 50V

C143 4822 126 14585 100nF 10% X7R 0805 50V

C144 9965 000 12588 1000pF 50V 5%

C151 4822 126 13486 15pF 2% NP0 63V

C296 9965 000 12559 100uF 16V 20%

C400 4822 126 14585 100nF 10% X7R 0805 50V

C401 4822 124 40207 100uF 20% 25V

C402 4822 126 13221 100pF 2% NP0 63V

C403 4822 126 13221 100pF 2% NP0 63V

C404 9965 000 12476 0,01uF 50V 20%

C405 9965 000 12524 0,047uF 50V 20%

C406 9965 000 12573 0,022uF 50V 20%

C408 9965 000 12522 4,7uF 50V 20%

C409 9965 000 12522 4,7uF 50V 20%

C410 9965 000 16316 1uF 50V 20%

C411 4822 126 13221 100pF 2% NP0 63V

C412 4822 126 14585 100nF 10% X7R 0805 50V

C413 4822 126 14585 100nF 10% X7R 0805 50V

C414 9965 000 12522 4,7uF 50V 20%

C415 9965 000 12522 4,7uF 50V 20%

C416 4822 124 40248 10uF 20% 63V

C417 4822 124 40248 10uF 20% 63V

C418 4822 126 14585 100nF 10% X7R 0805 50V

C419 9965 000 12476 0,01uF 50V 20%

C420 9965 000 12522 4,7uF 50V 20%

C421 9965 000 12522 4,7uF 50V 20%

C422 4822 126 14585 100nF 10% X7R 0805 50V

C423 9965 000 14448 470uF 50V 20%

C424 9965 000 12588 1000pF 50V 5%

C425 4822 126 14585 100nF 10% X7R 0805 50V

C426 9965 000 12522 4,7uF 50V 20%

C427 4822 126 14585 100nF 10% X7R 0805 50V

C428 9965 000 12588 1000pF 50V 5%

C429 9965 000 12559 100uF 16V 20%

C430 9965 000 14135 0,001uF 50V 10%

C432 4822 126 14585 100nF 10% X7R 0805 50V

C433 9965 000 12522 4,7uF 50V 20%

C434 4822 126 13221 100pF 2% NP0 63V

C435 9965 000 14136 0,1uF 50V 20%

C436 9965 000 14394 56PF 50V 5%

C437 5322 116 80853 560pF 50V 5%

C441 4822 126 13221 100pF 2% NP0 63V

C442 4822 126 13221 100pF 2% NP0 63V

C443 4822 126 13221 100pF 2% NP0 63V

C444 4822 126 13221 100pF 2% NP0 63V

C445 4822 126 13221 100pF 2% NP0 63V

C446 4822 126 13221 100pF 2% NP0 63V

C447 4822 126 13221 100pF 2% NP0 63V

C448 4822 126 13221 100pF 2% NP0 63V

C450 9965 000 16320 220uF 16V 20%

C500 4822 126 13221 100pF 2% NP0 63V

C501 4822 126 14585 100nF 10% X7R 0805 50V

C502 4822 126 14585 100nF 10% X7R 0805 50V

C504 4822 126 14585 100nF 10% X7R 0805 50V

C506 4822 126 14585 100nF 10% X7R 0805 50V

C510 9965 000 12588 1000pF 50V 5%

C511 9965 000 14138 1uF 25V 10%

C512 4822 126 14585 100nF 10% X7R 0805 50V

C513 4822 126 14585 100nF 10% X7R 0805 50V

C514 9965 000 12588 1000pF 50V 5%

C515 4822 126 14585 100nF 10% X7R 0805 50V

C516 4822 126 14585 100nF 10% X7R 0805 50V

C517 9965 000 14139 10uF 50V 20%

C518 9965 000 14139 10uF 50V 20%

C519 9965 000 14139 10uF 50V 20%

C520 9965 000 14139 10uF 50V 20%

C523 9965 000 14133 1uF 50V 20%

C525 4822 126 14585 100nF 10% X7R 0805 50V

C526 9965 000 14140 1000uF 50V 20%

C527 9965 000 14140 1000uF 50V 20%

C528 9965 000 12588 1000pF 50V 5%

C529 4822 126 13618 330pF 1% NPO 63V

C530 4822 126 13618 330pF 1% NPO 63V

C531 4822 126 13618 330pF 1% NPO 63V

C532 9965 000 16686 0,47uF 50V 10% X7R

C533 9965 000 16686 0,47uF 50V 10% X7R

C534 9965 000 16686 0,47uF 50V 10% X7R

C535 9965 000 16686 0,47uF 50V 10% X7R

C536 9965 000 14133 1uF 50V 20%

C537 9965 000 14133 1uF 50V 20%

C538 9965 000 14133 1uF 50V 20%

C539 9965 000 14133 1uF 50V 20%

C540 9965 000 14133 1uF 50V 20%

C541 9965 000 14133 1uF 50V 20%

C542 9965 000 14133 1uF 50V 20%

C543 9965 000 14133 1uF 50V 20%

C544 9965 000 14133 1uF 50V 20%

C545 9965 000 16686 0,47uF 50V 10% X7R

C546 9965 000 16686 0,47uF 50V 10% X7R

C547 9965 000 16686 0,47uF 50V 10% X7R

C548 9965 000 14220 0,1uF 50V 10%

C549 9965 000 14220 0,1uF 50V 10%

C550 9965 000 14220 0,1uF 50V 10%

C554 9965 000 14220 0,1uF 50V 10%

C555 9965 000 14220 0,1uF 50V 10%

C556 9965 000 14220 0,1uF 50V 10%

C557 4822 126 13221 100pF 2% NP0 63V

C558 4822 126 13221 100pF 2% NP0 63V

C559 4822 126 14585 100nF 10% X7R 0805 50V

C561 4822 126 14585 100nF 10% X7R 0805 50V

C562 4822 126 14585 100nF 10% X7R 0805 50V

C563 9965 000 12522 4,7uF 50V 20%

C566 9965 000 14138 1uF 25V 10%

C567 9965 000 14138 1uF 25V 10%

C568 4822 126 14585 100nF 10% X7R 0805 50V

C569 9965 000 12588 1000pF 50V 5%

C570 4822 126 14585 100nF 10% X7R 0805 50V

C571 9965 000 12588 1000pF 50V 5%

C572 4822 126 14585 100nF 10% X7R 0805 50V

C573 4822 126 14585 100nF 10% X7R 0805 50V

C574 4822 126 14585 100nF 10% X7R 0805 50V

C575 4822 126 14585 100nF 10% X7R 0805 50V

C576 9965 000 14139 10uF 50V 20%

C577 9965 000 14139 10uF 50V 20%

C579 4822 126 14585 100nF 10% X7R 0805 50V

C581 4822 126 14585 100nF 10% X7R 0805 50V

C582 9965 000 12588 1000pF 50V 5%

C583 9965 000 14140 1000uF 50V 20%

C584 9965 000 12588 1000pF 50V 5%

C585 4822 126 13618 330pF 1% NPO 63V

C586 4822 126 13618 330pF 1% NPO 63V

C587 9965 000 12588 1000pF 50V 5%

C588 9965 000 14133 1uF 50V 20%

C589 9965 000 14133 1uF 50V 20%

C590 9965 000 14133 1uF 50V 20%

C591 9965 000 14133 1uF 50V 20%

C592 9965 000 14133 1uF 50V 20%

C593 9965 000 14133 1uF 50V 20%

C594 9965 000 14133 1uF 50V 20%

C595 9965 000 14133 1uF 50V 20%

C596 9965 000 14133 1uF 50V 20%

C598 9965 000 14133 1uF 50V 20%

C599 9965 000 16686 0,47uF 50V 10% X7R

C900 9965 000 12558 220uF 16V 20%

C901 4822 126 14585 100nF 10% X7R 0805 50V

C902 4822 126 14585 100nF 10% X7R 0805 50V

C903 9965 000 12558 220uF 16V 20%

C904 4822 126 14585 100nF 10% X7R 0805 50V

C905 4822 126 14585 100nF 10% X7R 0805 50V

C906 9965 000 12558 220uF 16V 20%

C907 9965 000 14142 470uF 16V 20%

C908 9965 000 12588 1000pF 50V 5%

C909 9965 000 14142 470uF 16V 20%

C910 9965 000 12558 220uF 16V 20%

C911 9965 000 12558 220uF 16V 20%

C912 9965 000 12588 1000pF 50V 5%

C928 4822 126 14585 100nF 10% X7R 0805 50V

C929 4822 126 14585 100nF 10% X7R 0805 50V

C930 4822 126 14585 100nF 10% X7R 0805 50V

C931 4822 126 14585 100nF 10% X7R 0805 50V
