Philips MX3550D/37S - Page 51

8-11 8-11
ELECTRICAL PARTS LIST - MAIN BOARD ELECTRICAL PARTS LIST - MAIN BOARD
CAPACITORS
C934 9965 000 14136 0,1uF 50V 20%
C935 5322 122 32658 22pF 5% 50V
C936 9965 000 14136 0,1uF 50V 20%
C937 9965 000 14136 0,1uF 50V 20%
C938 9965 000 14143 1000uF 16V 20%
C2015 4822 126 14585 100nF 10% X7R 0805 50V
C2016 9965 000 12588 1000pF 50V 5%
C2017 4822 126 14585 100nF 10% X7R 0805 50V
C2018 9965 000 12588 1000pF 50V 5%
C2019 9965 000 12559 100uF 16V 20%
C2020 9965 000 12588 1000pF 50V 5%
C2021 4822 126 14585 100nF 10% X7R 0805 50V
C2022 9965 000 12588 1000pF 50V 5%
C2023 9965 000 12588 1000pF 50V 5%
C2024 4822 126 14585 100nF 10% X7R 0805 50V
C2025 9965 000 12588 1000pF 50V 5%
C2026 9965 000 12588 1000pF 50V 5%
C2027 4822 126 14585 100nF 10% X7R 0805 50V
C2028 4822 126 14585 100nF 10% X7R 0805 50V
C2029 4822 126 14585 100nF 10% X7R 0805 50V
C2030 9965 000 12588 1000pF 50V 5%
C2031 4822 126 14585 100nF 10% X7R 0805 50V
C2032 4822 126 14585 100nF 10% X7R 0805 50V
C2033 9965 000 12588 1000pF 50V 5%
C2036 4822 126 14585 100nF 10% X7R 0805 50V
C2052 4822 124 40207 100uF 20% 25V
C2053 4822 126 14585 100nF 10% X7R 0805 50V
C2056 9965 000 12588 1000pF 50V 5%
C2062 4822 126 14585 100nF 10% X7R 0805 50V
C2063 9965 000 12588 1000pF 50V 5%
C2064 4822 126 14585 100nF 10% X7R 0805 50V
C2065 9965 000 12588 1000pF 50V 5%
C2066 4822 126 14585 100nF 10% X7R 0805 50V
C2073 9965 000 14132 4700uF 50V 20%
C2074 5322 121 42578 1uF 50V 20%
C2076 4822 126 14585 100nF 10% X7R 0805 50V
C2079 4822 124 40207 100uF 20% 25V
C2092 2238 861 18339 33pF 1% 50V
C2094 2238 861 18339 33pF 1% 50V
C2095 9965 000 12588 1000pF 50V 5%
C2096 4822 126 14585 100nF 10% X7R 0805 50V
C2164 9965 000 12588 1000pF 50V 5%
C2165 9965 000 12588 1000pF 50V 5%
C2175 4822 126 14585 100nF 10% X7R 0805 50V
C2176 9965 000 12588 1000pF 50V 5%
C2204 4822 126 14585 100nF 10% X7R 0805 50V
C2208 9965 000 14133 1uF 50V 20%
C2216 9965 000 14220 0,1uF 50V 10%
C2247 4822 126 14585 100nF 10% X7R 0805 50V
C2248 9965 000 12588 1000pF 50V 5%
C2249 9965 000 12588 1000pF 50V 5%
C2250 4822 126 14585 100nF 10% X7R 0805 50V
C2252 9965 000 12588 1000pF 50V 5%
C2253 4822 126 14585 100nF 10% X7R 0805 50V
C2254 9965 000 12588 1000pF 50V 5%
C2255 4822 126 14585 100nF 10% X7R 0805 50V
C2256 4822 126 14585 100nF 10% X7R 0805 50V
C2257 9965 000 12588 1000pF 50V 5%
C2258 4822 126 14585 100nF 10% X7R 0805 50V
C2259 9965 000 12588 1000pF 50V 5%
C2260 4822 126 14585 100nF 10% X7R 0805 50V
C2261 9965 000 12588 1000pF 50V 5%
C2262 9965 000 12588 1000pF 50V 5%
C2263 4822 126 14585 100nF 10% X7R 0805 50V
C2264 4822 126 14585 100nF 10% X7R 0805 50V
C2265 4822 126 14585 100nF 10% X7R 0805 50V
C2268 9965 000 12588 1000pF 50V 5%
C2269 9965 000 12588 1000pF 50V 5%
C2270 9965 000 12588 1000pF 50V 5%
C2271 4822 126 14585 100nF 10% X7R 0805 50V
C2272 9965 000 12588 1000pF 50V 5%
C2273 4822 126 14585 100nF 10% X7R 0805 50V
C2274 4822 126 14585 100nF 10% X7R 0805 50V
C2275 9965 000 12588 1000pF 50V 5%
C2276 4822 126 14585 100nF 10% X7R 0805 50V
C2277 4822 126 14585 100nF 10% X7R 0805 50V
C2278 9965 000 12588 1000pF 50V 5%
C2279 4822 126 14585 100nF 10% X7R 0805 50V
C2280 9965 000 12588 1000pF 50V 5%
C2281 4822 126 14585 100nF 10% X7R 0805 50V
C2282 4822 126 14585 100nF 10% X7R 0805 50V
C2283 4822 126 14585 100nF 10% X7R 0805 50V
C2284 4822 126 14585 100nF 10% X7R 0805 50V
C2285 9965 000 12588 1000pF 50V 5%
C2286 9965 000 12588 1000pF 50V 5%
C2287 9965 000 12588 1000pF 50V 5%
C2288 4822 126 14585 100nF 10% X7R 0805 50V
C2289 9965 000 12588 1000pF 50V 5%
C2290 4822 126 14585 100nF 10% X7R 0805 50V
C2291 9965 000 12588 1000pF 50V 5%
C2292 4822 126 14585 100nF 10% X7R 0805 50V
C2293 9965 000 12588 1000pF 50V 5%
C2294 4822 126 14585 100nF 10% X7R 0805 50V
C2295 4822 126 14585 100nF 10% X7R 0805 50V
C2296 9965 000 12588 1000pF 50V 5%
C2297 9965 000 12588 1000pF 50V 5%
C2298 4822 126 14585 100nF 10% X7R 0805 50V
C2299 4822 126 14585 100nF 10% X7R 0805 50V
C2300 4822 126 14585 100nF 10% X7R 0805 50V
C2301 9965 000 12588 1000pF 50V 5%
C2302 4822 126 14585 100nF 10% X7R 0805 50V
C2303 9965 000 12588 1000pF 50V 5%
C2304 9965 000 12588 1000pF 50V 5%
C2305 9965 000 12588 1000pF 50V 5%
C2306 4822 126 14585 100nF 10% X7R 0805 50V
C2307 9965 000 12588 1000pF 50V 5%
C5011 9965 000 16686 0,47uF 50V 10% X7R
C5012 9965 000 16686 0,47uF 50V 10% X7R
C5015 9965 000 14220 0,1uF 50V 10%
C5016 9965 000 14220 0,1uF 50V 10%
C5019 9965 000 14138 1uF 25V 10%
C5020 9965 000 14138 1uF 25V 10%
C5021 9965 000 14138 1uF 25V 10%
C5022 9965 000 14138 1uF 25V 10%
C5023 9965 000 14220 0,1uF 50V 10%
C5024 5322 122 32331 1nF 10% 100V
C5031 9965 000 16688 1uF 25V 10%
C5032 9965 000 16688 1uF 25V 10%
C5033 9965 000 16688 1uF 25V 10%
C5034 9965 000 16688 1uF 25V 10%
C5035 9965 000 16688 1uF 25V 10%
C5036 9965 000 16688 1uF 25V 10%
C5037 9965 000 16688 1uF 25V 10%
C5038 9965 000 16688 1uF 25V 10%
C5039 9965 000 16688 1uF 25V 10%
C5040 9965 000 16688 1uF 25V 10%
C5041 9965 000 16688 1uF 25V 10%
C5042 9965 000 16688 1uF 25V 10%
C5801 9965 000 14141 0,01uF 50V +80-20%
C5802 9965 000 14141 0,01uF 50V +80-20%
RESISTORS
R1 9965 000 12482 47K 1/10W 5%
R2 9965 000 12515 2,2K 1/6W 5% CF
R3 9965 000 12515 2,2K 1/6W 5% CF
R41 4822 117 11373 100R 1% RC12H 0805
R42 4822 117 11373 100R 1% RC12H 0805
R103 4822 051 20122 1,2K 5% 0,1W
R105 4822 051 20008 0R JUMPER 0805
R107 4822 051 20008 0R JUMPER 0805
R108 4822 051 20301 300R 5% 0,1W
R109 4822 051 20472 4,7K 5% 0,1W
R111 2322 734 63309 33R 1/10W 5%
R112 2322 734 63309 33R 1/10W 5%
R113 2322 734 63309 33R 1/10W 5%
R114 4822 051 20472 4,7K 5% 0,1W
R116 4822 051 20472 4,7K 5% 0,1W
R118 4822 051 20472 4,7K 5% 0,1W
R120 4822 051 20472 4,7K 5% 0,1W
R121 4822 051 20102 1K 5% 0,1W
R122 2322 734 63309 33R 1/10W 5%
R123 2322 734 63309 33R 1/10W 5%
R124 2322 734 63309 33R 1/10W 5%
R125 2322 734 63309 33R 1/10W 5%
R126 2322 734 63309 33R 1/10W 5%
R129 4822 117 11504 270R 1% 0,1W
R130 4822 051 20102 1K 5% 0,1W
R131 4822 117 11927 75R 1% 0,1W
R132 4822 117 11927 75R 1% 0,1W
R133 4822 117 11927 75R 1% 0,1W
R134 4822 117 11927 75R 1% 0,1W
R135 4822 051 20008 0R JUMPER 0805
R137 2322 734 63309 33R 1/10W 5%
R139 2322 734 63309 33R 1/10W 5%
R143 4822 051 20008 0R JUMPER 0805
R144 4822 051 20472 4,7K 5% 0,1W
R145 4822 051 20472 4,7K 5% 0,1W
R146 4822 051 20008 0R JUMPER 0805
R147 2322 734 63309 33R 1/10W 5%
R148 2322 734 63309 33R 1/10W 5%
R149 2322 734 63309 33R 1/10W 5%
R150 2322 734 63309 33R 1/10W 5%
R151 2322 734 63309 33R 1/10W 5%
R152 2322 734 63309 33R 1/10W 5%
R154 2322 734 63309 33R 1/10W 5%
R155 2322 734 63309 33R 1/10W 5%
R156 2322 734 63309 33R 1/10W 5%
R157 2322 734 63309 33R 1/10W 5%
R158 2322 734 63309 33R 1/10W 5%
R159 4822 117 13577 330R 1% RC12H 0805 1,25W
R160 2322 734 63309 33R 1/10W 5%
R161 2322 734 63309 33R 1/10W 5%
R162 2322 734 63309 33R 1/10W 5%
R163 4822 051 20479 47R 5% 0,1W
R164 2322 734 63309 33R 1/10W 5%
R171 4822 051 20223 22K 5% 0,1W
R172 9965 000 12482 47K 1/10W 5%
R177 4822 051 20109 10R 5% 0,1W
R178 2322 734 63309 33R 1/10W 5%
R179 2322 734 63309 33R 1/10W 5%
R180 4822 051 20102 1K 5% 0,1W
R181 4822 051 20332 3,3K 5% 0,1W
R182 4822 051 20102 1K 5% 0,1W
R183 4822 051 20472 4,7K 5% 0,1W
R184 4822 051 20472 4,7K 5% 0,1W
R185 4822 051 20472 4,7K 5% 0,1W
R186 4822 051 20472 4,7K 5% 0,1W
R187 4822 051 20109 10R 5% 0,1W
R189 2322 734 63309 33R 1/10W 5%
R191 4822 051 20008 0R JUMPER 0805
R193 4822 051 20008 0R JUMPER 0805
R248 4822 051 20223 22K 5% 0,1W
R400 9965 000 14161 200R 1/10W 5%
R401 4822 117 11373 100R 1% RC12H 0805
R402 4822 051 20472 4,7K 5% 0,1W
R403 4822 117 11373 100R 1% RC12H 0805
R404 4822 117 11373 100R 1% RC12H 0805
R405 4822 116 83933 15K 1% 0,1W
