10-4
10-4
ELECTRICAL PARTS LIST - POWER BOARD ELECTRICAL PARTS LIST - POWER BOARD
MISCELLANEOUS
CN902 9965 000 12636
!
CONNECTOR 4 PIN P=3,96MM
F901 9965 000 12500
!
FUSE T3,15A 250V SLOW
RB905 9965 000 14203
!
WIRE W/PLUG 4P 120MM
RL901 9965 000 09708
!
RELAY GJ-SH-112DM 320R
RT901 9965 000 14204
!
NTC THERMISTER 5OHM 5A D13MM
SN901 9965 000 14205
!
SFH615A-3
CAPACITORS
C901 9965 000 16687
!
0,22uF 275V 20%
C902 9965 000 16687
!
0,22uF 275V 20%
C903 9965 000 14178
!
220uF 250V 20%
C904 9965 000 14178
!
220uF 250V 20%
C905 9965 000 14179
!
0,0022uF 400V 20%
C906 9965 000 14179
!
0,0022uF 400V 20%
C907 9965 000 14180 0,01uF 1KV 20%
C908 9965 000 14181 470pF 1KV 10%
C909 9965 000 14179
!
0,0022uF 400V 20%
C910 9965 000 14182 0,001uF 1KV 20%
C911 4822 124 40756 1uF 100V 20%
C912 9965 000 12529 0,1uF 50V +80-20%
C913 4822 124 40433 47uF 20% 25V
C914 9965 000 12533 220uF 25V 20%
C919 9965 000 12528 4700pF 50V 10%
C919"2" 9965 000 14184 10uF 50V 20% (BACK SOLDER)
C920 9965 000 12529 0,1uF 50V +80-20%
C925 9965 000 14182 0,001uF 1KV 20%
C926 4822 124 21913 1uF 20% 63V
C929 9965 000 12530 1000uF 25V 20% D=10
C930 5322 122 32331 1nF 10% 100V
C931 9965 000 14143 1000uF 16V 20% 85’C
C932 9965 000 14143 1000uF 16V 20% 85’C
C933 5322 122 32331 1nF 10% 100V
C938 5322 122 32331 1nF 10% 100V
C939 9965 000 14143 1000uF 16V 20% 85’C
C940 9965 000 14143 1000uF 16V 20% 85’C
C941 5322 122 32331 1nF 10% 100V
C945 9965 000 14181 470pF 1KV 10%
C947 9965 000 14140 1000uF 50V 20%
C948 9965 000 14140 1000uF 50V 20%
C949 5322 122 32331 1nF 10% 100V
C950 9965 000 14185 0,01uF 50V 10%
C951 9965 000 12529 0,1uF 50V +80-20%
C952 9965 000 14140 1000uF 50V 20%
C962 9965 000 12529 0,1uF 50V +80-20%
C963 9965 000 14179
!
0,0022uF 400V 20%
C964 9965 000 14179
!
0,0022uF 400V 20%
C964"2" 9965 000 14184 10uF 50V 20% (BACK SOLDER)
C965 9965 000 14182 0,001uF 1KV 20%
C966 9965 000 14182 0,001uF 1KV 20%
C967 9965 000 14182 0,001uF 1KV 20%
C968 9965 000 14179
!
0,0022uF 400V 20%
C969 9965 000 14185 0,01uF 50V 10%
C970 9965 000 12529 0,1uF 50V +80-20%
C971 4822 124 21913 1uF 20% 63V
C972 9965 000 16356 10uF 50V 20%
RESISTORS
R901 9965 000 14192 560K 1/2W 5%
R902 9965 000 14192 560K 1/2W 5%
R903 9965 000 14193 1M 1/2W 5% CF
R904 9965 000 14193 1M 1/2W 5% CF
R905 9965 000 14194 68K 2W 5%
R906 9965 000 14194 68K 2W 5%
R907 9965 000 16690 4,7R 1/4W 5%
R908 9965 000 14196 6,8R 1/6W 5%
R919 4822 050 21003 10K 1% 0,6W
R920 9965 000 12519 1K 1/6W 5% CF
R921 9965 000 12519 1K 1/6W 5% CF
R922 9965 000 09727 56K 1/6W 5% CF
R923 9965 000 14197 30K 1/6W 1% MF
R924 9965 000 12621 2K 1/6W 5%
R925 9965 000 14198 2,7K 1/6W 1% MF
R928 9965 000 16691 120R 1/2W 5%
R931 9965 000 14200 75R 1/6W 5% CF
R932 9965 000 12621 2K 1/6W 5%
R941 4822 050 24703 47K 1% 0,6W
R942 4822 050 22203 22K 1% 0,6W
R943 4822 050 21003 10K 1% 0,6W
R945 4822 050 21003 10K 1% 0,6W
R946 4822 050 21003 10K 1% 0,6W
R947 4822 050 24703 47K 1% 0,6W
R948 4822 050 22203 22K 1% 0,6W
R951 9965 000 14201 100R 1/4W 5% CF
R952 9965 000 12517 1R 1/2W 5%
R953 9965 000 16681 3,3M 1/2W 5% only /37/37S
COILS & FILTERS
L901 9965 000 16693 COIL 6uH 10,5TS 6A
L902 9965 000 16694 COIL 6uH 13,5TS 2UEW
L903 9965 000 16694 COIL 6uH 13,5TS 2UEW
T901 9965 000 14206
!
M/FILTER 1,7A L1:86TS L2:86TS
T902 9965 000 14207
!
STANDBY TRANSFO 120V /37/37S
T902 9965 000 14230
!
STANDBY TRANSFO 230V /22S
T903 9965 000 14208
!
POWER TRANSFROMER EE-42 50W
DIODES
BR901 9965 000 14176
!
KBU808 8A 800V SEP
D901 4822 130 11044
!
BYV26D
D902 4822 130 30621 1N4148
D903 4822 130 31438
!
1N4001G
D904 4822 130 30621 1N4148
D905 9965 000 14186
!
MUR1620CT 8A 200V
D906 5322 130 32677
!
1N5822
D907 9965 000 14187
!
HER204 2A/300V 50NS
D908 9965 000 14188
!
HER104 1A/300V 50NS
D909 4822 130 30621 1N4148
D910 4822 130 30621 1N4148
ZD901 9965 000 14209
!
P6KE200A
ZD902 9965 000 14210 ZENER 5,6-5,9V 0,5W
ZD903 4822 130 80272 MTZJ7,5C
TRANSISTORS & INTEGRATED CIRCUITS
IC903 9965 000 14189
!
TOP249 250W
IC904 4822 209 81397
!
TL431CLPST
Q903 5322 130 44115 2N2222A
Q904 5322 130 60082
!
TIP120
Q910 9965 000 02409 2N7000
Q912 9965 000 02409 2N7000
Q913 4822 130 41651 2SC2001L
Note: Only the parts mentioned in this list are normal service spare
parts.
