ENGLISH
C 2 Pull the top portion of the shaving unit
straight off the shaver.
C 3 Place the retaining ring holder on the
retaining ring (1), turn counterclockwise
(2) and lift it off the shaving head (3).
4 Remove the retaining ring from the
retaining ring holder and repeat the
process for the other retaining rings.
C 5 Remove the shaving heads from the
shaving head holder. Remove the cutter
from the comb.
Do not clean more than one cutter and comb
at a time, since they are all matching sets. If you
accidentally put a cutter in the wrong comb, it
may take several weeks before optimal shaving
performance is restored.
C 6 Clean the cutter and comb under warm
tap water.
C 7 After cleaning, place the cutter back into
the comb with the cutter legs pointing
downwards.
31
1 2
3
