Philips SLV3220 - Overview; Control and display elements

4
EN
Overview
Control and display elements
A Transmitter
1 Integrated remote control blaster light
2 On/off switch
3 Power light:
> red: standby
> green: on
4 TV2 source indicator
5 SOURCE button
6 Power input connector (DC 9V)
7 Wireless channel selection switch
8 SOURCE 2 connectors (red/white/yellow)
9 SCART cable
10 Remote control blaster cord port
B Receiver
12 Integrated remote control blaster light
13 On/off switch
14 Power light:
> red: standby
> green: on
15 Power input connector (DC 9V)
16 Wireless channel selection switch
17 SCART cable
F Remote control blaster cord
19 Connector
20 Blaster light
