Philips SW200 - Electrical Parts List - Power Board

4-3
ELECTRICAL PARTS LIST - POWER BOARD
MISCELLANEOUS
CN901 9965 000 12636
!
CONNECTOR 4 PIN P=3,96MM
CN902 9965 000 12636
!
CONNECTOR 4 PIN P=3,96MM
F901 4822 070 33152
!
FUSE T3,15A 250V SLOW /17/17S
F901 9965 000 16184
!
FUSE T4A 250V SLOW /00S/02S/15S
RL901 9965 000 09708
!
RELAY GJ-SH-112DM 320
T902 9965 000 12602
!
TRANSFORMER 120V 60HZ
T902 9965 000 15975
!
TRANSFORMER 230V 50HZ
CAPACITORS
C358 9965 000 12639 22UF 16V 20%
C359 9965 000 12559 100UF 16V 20%
C361 9965 000 12640 470UF 35V 20%
C362 2038 554 00065 100NF +80/-20% 50V
C363 9965 000 12559 100UF 16V 20%
C364 2038 554 00065 100NF +80/-20% 50V
C901 9965 000 12604
!
0,01UF 20% 250V
RESISTORS
R377 4822 050 22203 22K 1% 0,6W
R378 9965 000 12641 62K 1/6W 5%
R379 4822 116 83868 150R 5% 0,5W
R380 9965 000 12629 30K 1/6W 5%
R381 4822 050 24703 47K 1% 0,6W
R382 4822 116 52218 300R 5% 0,5W
R383 4822 116 52263 2K7 5% 0,5W
DIODES
D353 4822 130 30621 1N4148
D354 4822 130 31438
!
1N4001G
D355 4822 130 31438
!
1N4001G
D356 4822 130 31438
!
1N4001G
ZD350 9965 000 12642 ZENER 11,1-11,6V 0,5W
TRANSISTORS
Q354 4822 130 41198 2SC945P
Q355 4822 130 41198 2SC945P
Q357 4822 130 41198 2SC945P
Note: Only the parts mentioned in this list are normal service spare
parts.
