Philips SW200 - Mechanical & Accessories Parts List; Screw List

6-2
6-2
MECHANICAL & ACCESSORIES PARTS LIST - MAIN UINT
4 D3 x 10
5 D3 x 6
6 M4 x 25
14 M3 x 8
26 M2 x 6
27 D3 x 10
28 D3,5 x 14
31 M3 x 22
36 M3 x 14
49 M3 x 12
SCREW LIST - MAIN UINT
A1 9965 000 15982 FRONT PANEL ASSY /00S/02S/15S
A1 9965 000 14650 FRONT PANEL ASSY /17
A1 9965 000 14648 FRONT PANEL ASSY /17S
A2 9965 000 14651 CLOTH FRAME ASSY /00S/02S/17
A2 9965 000 14649 CLOTH FRAME ASSY /15S/17S
8 9965 000 12979
!
MAINS TRANSFO 120V /17/17S
8 9965 000 15970
!
MAINS TRANSFO 230V /00S/02S/15S
29 9965 000 12818
!
MAINS CORD FIXED /17/17S
29 9965 000 15980
!
MAINS CORD DETACHABLE AUST. /00S
29 9965 000 15983
!
MAINS CORD DETACHABLE /02S
30 9965 000 07092 BUSHING, FIXED CORD /15S/17/17S
38 4822 532 13065 WASHER
39 9965 000 08278 SPEAKER DRIVER 100W 6,5” 4OHM
44 9965 000 12981 RUBBER FOOT
48 9965 000 12443 Mains Socket /00S/02S
Note: Only the parts mentioned in this list are normal service spare
parts.
