Philips Semiconductors Preliminary specification
Video output amplifier TDA6111Q
FEATURES
• High bandwidth and high slew rate
• Black-current measurement output for Automatic
Black-current Stabilization (ABS)
• Two cathode outputs; one for DC currents, and one for
transient currents
• A feedback output separated from the cathode outputs
• Internal protection against positive appearing
Cathode-Ray Tube (CRT) flashover discharges
• ESD protection
• Simple application with a variety of colour decoders
• Differential input with a designed maximum common
mode input capacitance of 3 pF, a maximum differential
mode input capacitance of 0.5 pF and a differential input
voltage temperature drift of 50 µV/K
• Defined switch-off behaviour.
GENERAL DESCRIPTION
The TDA6111Q is a video output amplifier with 16 MHz
bandwidth. The device is contained in a single in-line 9-pin
medium power (DBS9MPF) package, using high-voltage
DMOS technology, intended to drive the cathode of a
colour CRT.
QUICK REFERENCE DATA
ORDERING INFORMATION
SYMBOL PARAMETER CONDITIONS MIN. TYP. MAX. UNIT
V
DDH
high level supply voltage 0 − 250 V
V
DDL
low level supply voltage 0 − 14 V
I
DDH
quiescent high voltage supply current V
oc
= 0.5V
DDH
7.0 9.0 11.0 mA
I
DDL
quiescent low voltage supply current V
oc
= 0.5V
DDH
5.0 6.8 8.0 mA
V
I
input voltage 0 − V
DDL
V
V
oc
, V
fb
output voltage V
DDL
− V
DDH
V
T
stg
storage temperature −55 − +150 °C
T
amb
operating ambient temperature −20 − +65 °C
TYPE NUMBER
PACKAGE
NAME DESCRIPTION VERSION
TDA6111Q DBS9MPF plastic DIL-bent-SIL medium power package with fin; 9 leads SOT111-1
