1996 Jan 08 2
Philips Semiconductors Product specification
2 × 40 W/2 Ω stereo BTL car radio
power amplifier with diagnostic facility
TDA8560Q
FEATURES
• Requires very few external components
• High output power
• 4 Ω and 2 Ω load impedance
• Low output offset voltage
• Fixed gain
• Diagnostic facility (distortion, short-circuit and
temperature detection)
• Good ripple rejection
• Mode select switch (operating, mute and standby)
• Load dump protection
• Short-circuit safe to ground, to V
P
and across the load
• Low power dissipation in any short-circuit condition
• Thermally protected
• Reverse polarity safe
• Electrostatic discharge protection
• No switch-on/switch-off plop
• Flexible leads
• Low thermal resistance.
GENERAL DESCRIPTION
The TDA8560Q is an integrated class-B output amplifier in
a 13-lead single-in-line (SIL) power package.
It contains 2 × 40 W/2 Ω amplifiers in BTL configuration.
The device is primarily developed for car radio
applications.
QUICK REFERENCE DATA
ORDERING INFORMATION
SYMBOL PARAMETER CONDITIONS MIN. TYP. MAX. UNIT
V
P
operating supply voltage 6.0 14.4 18 V
I
ORM
repetitive peak output current −−7.5 A
I
q(tot)
total quiescent current − 115 − mA
I
sb
standby current − 0.1 100 µA
I
sw
switch-on current −−40 µA
Z
I
 input impedance 25 30 − kΩ
P
o
output power R
L
=4Ω; THD = 10% − 25 − W
R
L
=2Ω; THD = 10% − 40 − W
SVRR supply voltage ripple rejection R
s
=0Ω−45 − dB
α
cs
channel separation R
s
=10kΩ−50 − dB
G
v
closed loop voltage gain 39 40 41 dB
V
no
noise output voltage R
s
=0Ω−−250 µV
∆V
O
 DC output offset voltage −−200 mV
TYPE NUMBER
PACKAGE
NAME DESCRIPTION VERSION
TDA8560Q DBS13P plastic DIL-bent-SIL power package; 13 leads (lead length 12 mm) SOT141-6
