1996 Jan 08 9
Philips Semiconductors Product specification
2 × 40 W/2 Ω stereo BTL car radio
power amplifier with diagnostic facility
TDA8560Q
AC CHARACTERISTICS
V
P
= 14.4 V; R
L
=4Ω; f = 1 kHz; T
amb
=25°C; measured in Fig.6; unless otherwise specified.
SYMBOL PARAMETER CONDITIONS MIN. TYP. MAX. UNIT
P
o
output power THD = 0.5% 16 19 − W
THD = 10% 21 25 − W
THD = 30% 28 35 − W
P
o
output power V
P
= 13.2 V
THD = 0.5% − 15 − W
THD = 10% − 21 − W
THD total harmonic distortion P
o
=1W − 0.1 − %
