TFA9843AJ
20 W stereo power amplifier with volume control
[1] The noise output voltage is measured at the output in a frequency range from 20 Hz to 22 kHz
(unweighted), with a source impedance Z
S
=0Ω at the input.
[2] Supply voltage ripple rejection is measured at the output, with a source impedance Z
S
=0Ω at the input
and with a frequency range from 20 Hz to 22 kHz (unweighted). The ripple voltage is a sine wave with a
frequency f
ripple
and an amplitude of 300 mV (RMS), which is applied to the positive supply rail.
[3] Output voltage in Mute mode (V
I(VC)
= 1.35 V) and an input voltage of 1 V (RMS) in a bandwidth from 20 Hz
to 22 kHz, including noise.
V
CC
= 18 V THD = 10 %
Fig 3. Voltage gain as a function of volume control
voltage
Fig 4. Output power (one channel) as a function of
supply voltage for various loads
001aae340
V
I(VC)
(V)
0 6.04.02.0
−50
−100
0
50
G
V
(dB)
−150
8
40
60
20
0
12 28
V
CC
(V)
16 20
P
o
(W)
24
mce485
R
L
= 1 Ω
8 Ω
4 Ω
3 Ω2 Ω
V
CC
= 18 V; f = 1 kHz; R
L
= 4 Ω V
CC
= 18 V; P
o
= 1 W; R
L
= 4 Ω
Fig 5. Total harmonic distortion-plus-noise as a
function of output power
Fig 6. Total harmonic distortion-plus-noise as a
function of frequency
10
2
10
1
10
−1
10
−2
mce488
10
−1
10
2
110
P
o
(W)
THD + N
(%)
10
1
10
−1
10
−2
001aaa446
10
THD+N
(%)
f (Hz)
10
2
10
3
10
4
10
5
