Revision List
EN 2 TPM16.1E LA1.
2016-Nov-11
back to
div.table
1. Revision List
Manual xxxx xxx xxxx.0
• First release.
Manual xxxx xxx xxxx.1
• Chapter 6: Updated table 6-3 Display code overview
.
2017/10/20
• Chapter 6: Updated the PSU standby output value.
• Chapter 10: Updated the PSU standby output value.
2. Technical Specs, Diversity, and Connections
Index of this chapter:
2.1 Technical Specifications
2.2 Directions for Use
2.3 Connections
2.4 Chassis Overview
Notes:
• Figures can deviate due to the different set executions.
• Specifications are indicative (subject to change).
2.1 Technical Specifications
For on-line product support please use the links in back to
div.table 2-1. Here is product information available, as well as
getting started, user manuals, frequently asked questions and
software & drivers.
Table 2-1 Described Model Numbers and Diversity
2.2 Directions for Use
Directions for use can be downloaded from the following
websites:
http://www.philips.com/support
http://www.p4c.philips.com
CTN
24 910 11
Connection Overview
Mechanics
Block Diagram
Schematics
Styling
Wire Dressing
Rear Cover Removal
Kyboard Control Removal
SSB Removal
Power Supply
SSB
J (IR/LED)
E (Keyboard/Leading Edge)
32PHS5301/12 2-1 4-1 4-4 & 4-5 4-6 4-7 9.1 10.1 10.3 10.4 10.5 11.1
32PHT5301/12 2-1 4-1 4-4 & 4-5 4-6 4-7 9.1 10.1 10.3 10.4 10.5 11.1
43PFS5301/12 2-1 4-2 4-4 & 4-5 4-6 4-7 9.1 10.2 10.3 10.4 10.5 11.2
43PFT5301/12 2-1 4-2 4-4 & 4-5 4-6 4-7 9.1 10.2 10.3 10.4 10.5 11.2
49PFS5301/12 2-1 4-3 4-4 & 4-5 4-6 4-7 9.1 10.2 10.3 10.4 10.5 11.3
49PFT5301/12 2-1 4-3 4-4 & 4-5 4-6 4-7 9.1 10.2 10.3 10.4 10.5 11.3
