Philips V30 107T50 - Static EHT Regulation Distortion Pattern

71
107T5
GENERAL PRODUCT SPECIFICATION
Go to cover page
17" V30 GS4 107T5-71K CMTR
TYPE : 107T51/00
BRAND : PHILIPS
2003-01-07
Wayne Lin
2003-01-07
30
29590
306 mm
A
B
C
D
SLOW FLASHING WHITE PATTERN
STATIC BORDER
230 mm
DA < 1.50 mm
DB < 1.50 mm
DC < 1.20 mm
DD < 1.20 mm
(D measured between
flash on / off)
Figure 7
Static EHT regulation distortion pattern
