Philips vr530 - Mechanical Parts List; Mechanical Component Cross-Reference

MECHANICAL PARTS LIST
Pos.
h
12 NC Description
A1X 9965 000 12888 FRONT ASSEMBLY HC265ED 1
A1X 9965 000 12900 FRONT ASSEMBLY HC266BD 1
A1X 9965 000 12902 FRONT ASSEMBLY HC267FD 1
A1X 9965 000 12910 FRONT ASSEMBLY HC463FD 1
A1X 9965 000 12911 FRONT ASSEMBLY HC465ED 1
A1X 9965 000 12163 FRONT ASSEMBLY HC466BD 1
A1X 9965 000 12912 FRONT ASSEMBLY HC467ED 1
A1X 9965 000 12253 FRONT ASSEMBLY HC468FD 1
A2 9965 000 12164 CASE, TOP HC460ED 11111111
A3 9965 000 12165 CHASSIS HC461BD 11111111
A7 9965 000 12166 PANEL, BOTTOM HC461BD 11111111
A10
h
LABEL, RATING HC265ED 1
A10
h
LABEL, RATING HC468FD 1 1
A10
h
LABEL, RATING HC267FD 1
A10
h
LABEL, RATING HC463FD 1 1
A10
h
LABEL, RATING HC465ED 1 1
A14 LABEL, BAR CODE HC265ED 1
A14 LABEL, BAR CODE HC468FD 1 1
A14 LABEL, BAR CODE HC267FD 1
A14 LABEL, BAR CODE HC463FD 1 1
A14 LABEL, BAR CODE HC465ED 1 1
1B1 9965 000 12889 DECK ASSEMBLY CZD011/VM15A0 1 1
1B1 9965 000 12903 DECK ASSEMBLY CZD011/VM15A1 1
1B1 9965 000 12399 DECK ASSEMBLY CZD011/VM15E0 11111
2B5 9965 000 12168 SHEILD, CYLINDER HC460ED 11111111
2B18 9965 000 12400 FIBER, TOP CASE HC460ED 11111111
2B49 9965 000 12402 CHASSIS FIBER HC460ED 11111111
2L011 9965 000 12403 SCREW, P-TIGHT 3X12 BIND HEAD+ 11111111
2L012 9965 000 12403 SCREW, P-TIGHT 3X12 BIND HEAD+ 11111111
2L021 4822 502 30752 SCREW, P-TIGHT M3X10 WASHER HEAD+ 11111111
2L031 9965 000 12171 SCREW, B-TIGHT M3X8 BIND HEAD+ 11111111
2L041 4822 502 14012 P-TIGHT SCREW 3X8 BIND + 11111111
2L042 4822 502 14012 P-TIGHT SCREW 3X8 BIND + 11111111
2L043 4822 502 14012 P-TIGHT SCREW 3X8 BIND + 11111111
2L051 4822 502 14018 SCREW, S-TIGHT M3X5 BIND HEAD+ 11111111
X1 9965 000 12890 REMOTE CONTROL UNIT 364/CRC006 or 1 1 1
X1 9965 000 12281 REMOTE CONTROL UNIT 364/CRC006 or 1
X1 9965 000 12172 REMOTE CONTROL UNIT 364/CRC006 1111
X3 9965 000 09742 RF CORD PAL 1.2M 11111111
X6 9965 000 12420 21P SCART CABLE or 1 1 1
VR630/39 VR630/16 VR330/07 VR530/39 VR630/07
PRODUCT SAFETY NOTE: Products marked with a h
have special characteristics important to safety.
Before replacing any of these components, read carefully
the product safety notice in this service manual.
Don’t degrade the safety of the product through improper servicing.
VR330/02 VR330/39 VR630/02
