Switch off
the power
Prohibition
Please switch off the power for clean or maintenance.
It is prohibited to use copper or iron as fuse. The right fuse
must be fixed by electrician for the heat pump.
It is prohibited to spray the flammable gas to the heat pump,
as it may cause fire.
Installation
Operation
Prohibition
安装前注意事项
ATTENTION
Check the
installation basement
Please check the installation basement in a period (one month),
to avoid any decline or damage on the basement, which may
hurt people or damage the unit
Safety Precaution
Meaning
Fix the unit
Installation Place
Need
circuit breaker
The unit CANNOT be installed near the flammable gas.
Once there is any leakage of the gas, fire can be occur.
Make sure that the basement of the heat pump is strong
enough, to avoid any decline or fall down of the unit
Make sure that there is circuit breaker for the unit, lack of
circuit breaker can lead to electrical shock or fire.
Meaning
Specification
2 Appearance and structure of the unit：
1 Nomenclature of the heat pump
4: mode C--cooling only R--heating and cooling D--aux-electrical heater
3: system loop X--gas loop S--water loop
6: capacity nominated cooling or heating capacity (3 figures，horsepower/10）
2: heat source A--air source W--water source
1: P--Product
5: outdoor unit type W--monobloc type F--split type
7: power supply (omit)--single phase power S--three phase power
For example: PASCW060B-V stand for air source water chiller with 6 horsepower
cooling capacity(15kw) and with water pump
8: water pump (omit)-no water pump B--water pump included
9: Appendix V- the shape of condenser
P A S R W 050 S B- V- T D
1 2 3 4 5 6 7 8 9 10 11
Wire
controller
The maximum cable for
the wire controller is 200
metres from the heat pump.
10: water tank (omit)--no water tank T--water tank included
11: Auxiliary electrical heater (omit)--without auxiliary electrical heater
D--with auxiliary electrical heater
5
4
