16
When mounting the controller with
screws, make sure to use screws that
suit the attachment material (use
screws with 4 mm shaft and max. 8
mm head diameter, no counter sink).
Keep in mind that the screws also have
to carry the force applied by the wiring.
Make sure that the ventilator slits on
the sides are unobstructed.
The controller is intended for indoor use only. Protect it from
direct sunlight and place it in a dry environment. Never install it
in humid rooms (like bathrooms). The controller measures the
ambient temperature to determine the charging voltage. Controller
and battery must be installed in the same room.
The controller warms up during operation, and should therefore
be installed on a non flammable surface only.
Mounting and Connecting
REMARK: Connect the controller by following the steps described
below to avoid installation faults.
