Line Mixer Settings
Select line mixer when receiving a line-level microphone signal from a pre-amplified source.
Settings are similar to those for the microphone mixer. The line mixer setting applies to inputs:
noise cancellation, echo cancellation, and automatic gain control. The line mixer limits the total
number of line inputs to four (4) and disables the microphone inputs.
Speaker Tab – Use the master-volume slider to adjust the loudspeaker output level and control
overall volume. Level the audio by balancing loudspeaker output received from USB, SIP and
analog inputs.
Line Tabs – Each line input has its own setting. Select podium, auxiliary or mixer. The message
“not set” indicates that a line is not functional.
The line mixer setting concentrates a voice signal using beamforming technology. Unless you
use the mixer setting, a signal is not beamformed.
