Process, parameter, and diagnostic data
109745_en_01 PHOENIX CONTACT 41 / 66
7.1.6 Output process data of CAPAROC E2 12-24DC/2-10A
The CAPAROC E2 12-24DC/2-10A 2-channel circuit breaker module has 2 bytes of output
process data, which is defined as follows:
The internal validity flag prevents a non-initialized process data byte from causing the
unintentional shutdown of an output channel. The signal for switch-on or switch-off
must be applied for at least 1500 ms. Internally, only one validity flag is available per
module. The rest of the output process data for this module is also deemed valid as
soon as either of the two flags is set to “1”.
Table 7-6 Output process data of CAPAROC E2 12-24DC/2-10A
Byte
offset
Data
type
Bit Description Value range
0 Byte 0 Switch channel 1 0 = channel 1 off
1 = channel 1 on
1 ... 6 Reserved 0
7 Internal validity flag 1
1 Byte 0 Switch channel 2 0 = channel 2 off
1 = channel 2 on
1 ... 6 Reserved 0
7 Internal validity flag 1
