PLC / Modbus/RTU
105542_en_05 PHOENIX CONTACT 85 / 198
6.8.1 I/O integration in Phoenix Contact controllers
Figure 6-9 I/O integration in PC Worx
Required components:
– Radioline front module
– Radioline I/O extension modules
– Inline or Axioline controllers
– Inline or Axioline RS-485 communication module
–PC Worx
– PC Worx function blocks
– PCW_6_RadiolineBasic
– PCW_6_ComSerial
– PCW_6_Modbus
